Mean Well PLD-16-1050A Power Supply 16W 1050mA
Please Login for Pricing
Description
Description
The PLD-16 is a 16W Mean Well power converter (input range: 24~48V, operating temperature: -30~+50℃).
Key Features
- ✓ Input voltage range: 24~48V
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -30~+50℃
- ✓ Protections: Short circuit / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: UL8750,CSA C22.2 No.250.0-08(except for PLD-16-350);ENEC EN 613471-1,EN 61347-2-13 independent, EN62384(for B type only), IP42
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesPLD Series
-
Power Rating16.8 Watt
-
Output Voltage16 Volt
-
Rated Current1.05 Ampere
-
Input Voltage90V~135V
-
Standards MetCE,cUL,EAC,ENEC,FCC
-
Operation ModeConstant Current
-
Operating Temperature-30°C~50°C
-
Warranty3 Year
-
Length8.4 cm
-
Width5.7 cm
-
Height2.95 cm
-
Weight0.19 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the PLD-16-1050A for a small LED downlight?
Yes, if the downlight is designed for a constant current driver at 1050mA. The LED load also needs a total forward voltage that stays within the 12-16V constant current range and within the 16.8W rating.
Is this driver suitable for signage LED modules?
It can be used for signage modules only when the modules are built for constant current operation at 1050mA. The connected module string must fall inside the 12-16V CC output range, and it is not intended for constant voltage signage products.
Can the PLD-16-1050A run a small LED array?
Yes, for a small LED array that requires 1050mA constant current. The array's total forward voltage must stay within 12-16V, and the exact number of LEDs depends on the forward voltage of each LED.
Can I use this driver for constant voltage LED strips?
No, this model is a constant current driver with a 1050mA output. It is meant for LED loads that operate within the 12-16V CC range, not for constant voltage strip lighting.
How do I know if my LED load is compatible with the PLD-16-1050A?
Match the LED load to 1050mA constant current and keep the total forward voltage within 12-16V. The number of LEDs you can run depends on each LED forward voltage, so compatibility is based on the full LED load rather than a fixed LED count.
Is the PLD-16-1050A suitable for damp or exposed outdoor locations?
This driver has an IP42 rating in a plastic case, so it is better suited to indoor areas where only limited exposure is expected. Its operating temperature range is -30°C to +50°C, but IP42 is not intended for direct weather exposure.
Other PLD-16 Models
7 other models| Model | Power | Voltage | Current | IP Rating | |
|---|---|---|---|---|---|
| Mean Well PLD-16-700B Power Supply 16W 700mA | 16.8W | 24V | 0.7A | Indoor | View |
| Mean Well PLD-16-700A Power Supply 16W 700mA | 16.8W | 24V | 0.7A | Indoor | View |
| Mean Well PLD-16-350B Power Supply 16W 350mA | 16.8W | 48V | 0.35A | Indoor | View |
| Mean Well PLD-16-350A Power Supply 16W 350mA | 16.8W | 48V | 0.35A | Indoor | View |
| Mean Well PLD-16-1400B Power Supply 16W 1400mA | 16.8W | 12V | 1.4A | Indoor | View |
| Mean Well PLD-16-1400A Power Supply 16W 1400mA | 16.8W | 12V | 1.4A | Indoor | View |
| Mean Well PLD-16-1050B Power Supply 16W 1050mA | 16.8W | 16V | 1.05A | Indoor | View |
