Mean Well PLD-16-700A Power Supply 16W 700mA
Please Login for Pricing
Description
Description
The PLD-16 is a 16W Mean Well power converter (input range: 24~48V, operating temperature: -30~+50℃).
Key Features
- ✓ Input voltage range: 24~48V
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -30~+50℃
- ✓ Protections: Short circuit / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: UL8750,CSA C22.2 No.250.0-08(except for PLD-16-350);ENEC EN 613471-1,EN 61347-2-13 independent, EN62384(for B type only), IP42
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesPLD Series
-
Power Rating16.8 Watt
-
Output Voltage24 Volt
-
Rated Current0.7 Ampere
-
Input Voltage90V~135V
-
Standards MetCE,cUL,EAC,ENEC,FCC
-
Operation ModeConstant Current
-
Operating Temperature-30°C~50°C
-
Warranty3 Year
-
Length8.4 cm
-
Width5.7 cm
-
Height2.95 cm
-
Weight0.19 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the PLD-16-700A with a 700mA LED downlight?
Yes, if the downlight is designed for constant current operation at 700mA and its LED load falls within the 16-24V constant current range. This driver is rated for 16.8W, which fits compact downlight assemblies in that electrical window. It is not intended for downlights that expect a constant voltage input.
Will the PLD-16-700A work for small LED arrays?
It will work for small LED arrays that require 700mA constant current and have a combined forward voltage between 16V and 24V. The exact number of LEDs depends on the forward voltage of each LED in the array. The driver's maximum output power is 16.8W.
Is this a good choice for compact LED signage modules?
It can be, but only for signage modules engineered for 700mA constant current input within the 16-24V CC range. Many signage products use constant voltage systems, and those are not compatible with this driver. This model is for constant current loads only.
How should I size the PLD-16-700A for my LEDs?
Match it to LED loads that need 700mA constant current and operate across 16-24V on the output side. The number of LEDs depends on the forward voltage of each LED, so the correct load is determined by total forward voltage rather than a fixed LED quantity. The load also needs to stay within the 16.8W rating.
Where can the PLD-16-700A be used from an environmental standpoint?
The PLD-16-700A uses an IP42 plastic case, so it is intended for protected environments rather than direct outdoor exposure. Its operating temperature range is -30°C to +50°C. The Class II design without FG is useful where that insulation class is required, but it does not change the IP42 limitation.
Other PLD-16 Models
7 other models| Model | Power | Voltage | Current | IP Rating | |
|---|---|---|---|---|---|
| Mean Well PLD-16-700B Power Supply 16W 700mA | 16.8W | 24V | 0.7A | Indoor | View |
| Mean Well PLD-16-350B Power Supply 16W 350mA | 16.8W | 48V | 0.35A | Indoor | View |
| Mean Well PLD-16-350A Power Supply 16W 350mA | 16.8W | 48V | 0.35A | Indoor | View |
| Mean Well PLD-16-1400B Power Supply 16W 1400mA | 16.8W | 12V | 1.4A | Indoor | View |
| Mean Well PLD-16-1400A Power Supply 16W 1400mA | 16.8W | 12V | 1.4A | Indoor | View |
| Mean Well PLD-16-1050B Power Supply 16W 1050mA | 16.8W | 16V | 1.05A | Indoor | View |
| Mean Well PLD-16-1050A Power Supply 16W 1050mA | 16.8W | 16V | 1.05A | Indoor | View |
