Mean Well SPAN02A-03 DC-DC Converter - 2W - 9~18V in 3.3V out
Please Login for Pricing
Description
Description
SPAN02 and DPAN02 series are 2W isolated and regulated module type DC-DC converter with SIP8 package. It features international standard pins, a high efficiency up to 85%, wide working temperature range -40~+90℃, 1.5KVDC I/P-O/P isolation voltage, compliance to EN55032 radiated class A without additional components, overload and continuous-mode short circuit protection, etc. The models account for different input voltage 4.5~9V, 9~18V, 18~36V and 36~75V 2:1 wide input range, and various output voltage, 3.3V/5V/12V/15V for single output and ±5V/±12V/±15V for dual outputs, which are suitable for all kinds of systems, such as industrial control, telecommunication field, distributed power architecture, and so on.
Features
- SIP8 package with industry standard pinout 2:1 wide input range
- Operating temperature range -40 ~ +90℃
- No minimum load required
- Comply to EN55032 radiated Class A without additional
- Hcoigmhpeofnfiecinetnscy up to 85%
- Protections: Short circuit (Continuous) / Overload
- 1.5KVDC I/O isolation
- Remote ON/OFF control
- 3 years warranty
Applications
- Telecom/datacom system
- Wireless network
- Industrial control facility
- Instrument
- Analyzer
- Detector
- Data switch
Specifications
Specifications
-
BrandMean Well
-
SeriesSPAN Series
-
Power Rating2 Watt
-
Output Voltage3.3 Volt
-
Rated Current0.5 Ampere
-
Input Voltage9V~18V
-
Standards MetCE,EAC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length2.18 cm
-
Width1.11 cm
-
Height0.92 cm
-
Weight0 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the SPAN02A-03 to power 3.3V embedded control electronics?
It is suited to low-power embedded or industrial logic circuits that need a regulated 3.3V output from a 9-18VAC input source. With a 2W constant-voltage rating, it is intended for small electronics and control sections within that power level.
Is this a good fit for a 3.3V sensor or communications module in automation equipment?
Yes, when the module requires 3.3V constant voltage and the available input is within 9-18VAC. The 2W rating and compact 21.8 × 11.1 × 9.2 mm size make it more appropriate for low-power sensing, telemetry, or interface circuits.
Would the SPAN02A-03 work in a low-voltage control panel with a 3.3V logic rail?
It can fit low-voltage control designs that have a 9-18VAC source and need a dedicated 3.3V rail. The listed output current is 500A and the converter operates in constant-voltage mode.
Can this model support compact industrial IoT or monitoring hardware?
It is relevant for compact monitoring or embedded hardware that uses 3.3V and stays within the converter's 2W capacity. Its 0.0048 kg weight and small form factor are also useful where space is limited.
Is the SPAN02A-03 intended for indoor or outdoor environments?
The operating temperature range is -40°C to +90°C, which supports use across a wide set of temperature conditions. An IP rating is not provided in the specs, so outdoor or sealed-enclosure suitability is not defined here.
How does the SPAN02A-03 differ from the other SPAN02A models?
The SPAN02A-03, SPAN02A-05, SPAN02A-12, and SPAN02A-15 all have 2W power, 9-18VAC input, 21.8 × 11.1 × 9.2 mm dimensions, 0.0048 kg weight, and a -40°C to +90°C operating range. The outputs differ: 3.3V with listed 500A, 5V with listed 400A, 12V with listed 167A, and 15V with listed 134A.
