Mean Well SPAN02E-15 DC-DC Converter - 2W - 4.5~9V in 15V out
Please Login for Pricing
Description
Description
SPAN02 and DPAN02 series are 2W isolated and regulated module type DC-DC converter with SIP8 package. It features international standard pins, a high efficiency up to 85%, wide working temperature range -40~+90℃, 1.5KVDC I/P-O/P isolation voltage, compliance to EN55032 radiated class A without additional components, overload and continuous-mode short circuit protection, etc. The models account for different input voltage 4.5~9V, 9~18V, 18~36V and 36~75V 2:1 wide input range, and various output voltage, 3.3V/5V/12V/15V for single output and ±5V/±12V/±15V for dual outputs, which are suitable for all kinds of systems, such as industrial control, telecommunication field, distributed power architecture, and so on.
Features
- SIP8 package with industry standard pinout 2:1 wide input range
- Operating temperature range -40 ~ +90℃
- No minimum load required
- Comply to EN55032 radiated Class A without additional
- Hcoigmhpeofnfiecinetnscy up to 85%
- Protections: Short circuit (Continuous) / Overload
- 1.5KVDC I/O isolation
- Remote ON/OFF control
- 3 years warranty
Applications
- Telecom/datacom system
- Wireless network
- Industrial control facility
- Instrument
- Analyzer
- Detector
- Data switch
Specifications
Specifications
-
BrandMean Well
-
SeriesSPAN Series
-
Power Rating2 Watt
-
Output Voltage15 Volt
-
Rated Current0.13 Ampere
-
Input Voltage4.5V~9V
-
Standards MetCE,EAC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length2.18 cm
-
Width1.11 cm
-
Height0.92 cm
-
Weight0 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the SPAN02E-15 for a low-power 15V control circuit in automation equipment?
It can fit low-power 15V electronics because it provides a constant 15V output with a 2W rating. That makes it more appropriate for compact control and interface sections than for larger 15V loads.
Is the SPAN02E-15 suitable for embedded 15V signal or monitoring electronics?
Yes, it is aligned with low-power 15V embedded applications that need constant voltage. The 2W output level keeps it in the range for small electronics rather than higher-demand devices.
Can this model be used in compact industrial or communications hardware that needs 15V?
It can be a fit where a small 15V constant-voltage rail is needed and the load remains within 2W. Its 21.8 × 11.1 × 9.2 mm body also helps in space-constrained hardware.
Is the SPAN02E-15 a good choice for very small embedded assemblies?
The unit measures 21.8 × 11.1 × 9.2 mm and weighs 0.0048 kg, so it is well suited to compact layouts. That size is consistent with low-power embedded integration.
Can the SPAN02E-15 be used in outdoor or extreme-temperature environments?
The specified operating temperature range is -40°C to +90°C, so the temperature capability is broad. No IP rating is listed in the provided specs, so it should be considered for protected environments rather than exposed outdoor use.
What are the output differences across the SPAN02E series?
The SPAN02E family shares 2W power, constant-voltage operation, 21.8 × 11.1 × 9.2 mm dimensions, 0.0048 kg weight, and a -40°C to +90°C operating range. The available outputs are 3.3V at 500A, 5V at 400A, 12V at 167A, and 15V at 134A for the SPAN02E-15.
