Mean Well XTR-960-48LA Three Phase Din Rail Power Supply 960W 48V - Lever-Actuated 20A

The XTR-960-48LA is rated for 960W output power with a 48V DC output. Its rated output current is 20A, making it suitable for higher-power industrial DC loads within those limits.

This model is designed for industrial power systems that need stable 48V DC power at up to 960W. It is well suited to larger control cabinets, automation systems, and other demanding industrial environments where DIN rail power supplies are commonly used.

The XTR-960-48LA supports a three-phase 320 to 600Vac wide input range. The product description also notes that dual phase operation is possible, which may be useful in some industrial power environments.

This model is specified for operation from -40°C to 85°C. That wide temperature range supports use in challenging industrial settings where ambient conditions can vary significantly.

The XTR-960-48LA provides 960W of output power, which places it in a higher-capacity class than many compact DIN rail power supplies. It is a better fit when the application requires a 48V output and up to 20A of available current.

Yes. The XTR-960 series supports parallel operation, which can help with scalability in power distribution designs. Any use of parallel operation should follow the product documentation and the requirements of the overall system design.

The XTR-960-48LA is listed with a 5-year warranty period. Its listed weight is 1.8 kg, which is useful to account for when planning panel space and equipment handling.
