Overview
This kit is assembled from Vimar parts: 1 × plate 2centlM techn. (VM-14652.05); 1 × frame 2centralM +screws (VM-14612); 1 × 1P 16AX 1-way switch 2M (VM-14001.2). Each part's specifications follow, with a link to its own page.
Specifications
Kit contents
- Cover plate × 1
- VM-14652.05 · plate 2centlM techn. black
- Frame × 1
- VM-14612 · frame 2centralM +screws
- Installation switch × 1
- VM-14001.2 · 1P 16AX 1-way switch 2M white
Cover plate (VM-14652.05)
- Product type
- Cover frame for domestic switching devices
- Number of units
- 2
- Mounting direction
- Horizontal and vertical
- Number of device inserts horizontal
- 2
- Number of device inserts vertical
- 1
- Number of modules horizontal (module system)
- 2
- Number of modules vertical (module system)
- 1
- With mounting grid
- Yes
- Suitable for subfloor installation duct box
- Yes
- Suitable for wall duct
- Yes
- Suitable for built-in installation
- Yes
- Label space/information surface
- Yes
- Material
- Plastic
- Material quality
- Thermoplastic
- Halogen free
- Yes
- Surface protection
- Untreated
- Surface finishing
- Glossy
- Colour
- Black
- RAL-number (similar)
- 9005
- Degree of protection (IP)
- IP00
- Type of fastening
- Clamp mounting
- Width
- 120 mm
- Height
- 80 mm
- Depth
- 9 mm
- Built-in width
- 120 mm
- Built-in height
- 80 mm
- Certifications
- CE marking (EU), IMQ (Italy)
Frame (VM-14612)
- Product type
- Holder for modular domestic switching devices
- Model
- Flush-mounted
- Mounting method of the module inserts
- Front side
- Mounting direction
- Horizontal and vertical
- Number of modules horizontal (module system)
- 2
- Number of modules vertical (module system)
- 1
- With screws
- Yes
- Flush-mounted installation
- Yes
- Material
- Plastic
- Material quality
- Thermoplastic
- Surface protection
- Untreated
- Certifications
- CE marking (EU), IMQ (Italy)
Installation switch (VM-14001.2)
- Product type
- Installation switch
- Wiring system
- Switch 1-pole
- Operating method
- Rocker/button
- Assembly arrangement
- Modular device for domestic switching devices
- Number of modules (module system)
- 2
- Push button switch
- Yes
- Number of rockers
- 1
- Mounting method
- Flush-mounted
- Type of fastening
- Engage (snap)
- Material
- Plastic
- Material quality
- Thermoplastic
- Halogen free
- Yes
- Surface protection
- Untreated
- Surface finishing
- Glossy
- Colour
- White
- RAL-number (similar)
- 9003
- Label space/information surface
- Yes
- Lighting
- Optional
- Function lighting
- Control and orientation
- Type of lighting
- LED exchangeable
- Suitable for degree of protection (IP)
- IP40
- Nominal voltage
- 250 V
- Rated current
- 16 A
- Connection type
- Screwed terminal
- Device width
- 44.8 mm
- Device height
- 49 mm
- Device depth
- 38.4 mm
- Built-in depth
- 24 mm
- Certifications
- CE marking (EU), TISI (Thailand), IMQ (Italy), RCM (Australia), TSE (Turkey), CCC (China), SASO (Saudi Arabia), WEEE Directive
Technical drawings
Downloads
FAQ
What is the Vimar Plana Plastic 1 Gang Switch used for?
This parent product is a Vimar Plana 1 gang switch in black, intended for light switch and switch package selections in the Plana series. It is suited to B2B product pages where buyers are matching a black Plana-style 1 gang switch to a project specification.
What colour and finish is this Vimar Plana 1 gang switch?
The listed finish colour is black. The product name also identifies it as a plastic Vimar Plana switch, so it should be selected where a black Plana switch appearance is required.
What is the current rating of this switch?
The product name lists this Vimar Plana Plastic 1 Gang Switch as 16A. No other electrical performance specifications are provided in the parent or variant data.
What are the dimensions of the parent product?
The parent product dimensions are listed as 80.0000 mm length, 120.0000 mm width, and 9.0000 mm height. The listed weight is 1.0000 kg.
Do the listed child variants have different finishes or warranty periods?
The child variants shown both use the same black finish colour and the same 3.0000 year warranty period. The provided variant data does not show differences in colour, power rating, dimming control, driver, beam angle, CRI, brightness, or cut-out dimensions.
What warranty period is listed for this Vimar Plana switch family?
The parent product lists a 3.0000 year warranty period. The child variant data also shows a 3.0000 year warranty period for the variants provided.
