This kit is assembled from Vimar parts: 1 × plate 2centrM techn. (VM-14652.01); 1 × frame 2centralM +screws (VM-14612); 1 × 1P 16AX 1-way switch 2M (VM-14001.2). Each part's specifications follow, with a link to its own page.
Specifications
Kit contents
- Cover plate × 1
- VM-14652.01 · plate 2centrM techn. white
- Frame × 1
- VM-14612 · frame 2centralM +screws
- Installation switch × 1
- VM-14001.2 · 1P 16AX 1-way switch 2M white
Cover plate (VM-14652.01)
- Product type
- Cover frame for domestic switching devices
- Number of units
- 2
- Mounting direction
- Horizontal and vertical
- Number of device inserts horizontal
- 2
- Number of device inserts vertical
- 1
- Number of modules horizontal (module system)
- 2
- Number of modules vertical (module system)
- 1
- With mounting grid
- Yes
- Suitable for subfloor installation duct box
- Yes
- Suitable for wall duct
- Yes
- Suitable for built-in installation
- Yes
- Label space/information surface
- Yes
- Material
- Plastic
- Material quality
- Thermoplastic
- Halogen free
- Yes
- Surface protection
- Untreated
- Surface finishing
- Glossy
- Colour
- White
- RAL-number (similar)
- 9016
- Degree of protection (IP)
- IP00
- Type of fastening
- Clamp mounting
- Width
- 120 mm
- Height
- 80 mm
- Depth
- 9 mm
- Built-in width
- 120 mm
- Built-in height
- 80 mm
- Certifications
- CE marking (EU), IMQ (Italy)
Frame (VM-14612)
- Product type
- Holder for modular domestic switching devices
- Model
- Flush-mounted
- Mounting method of the module inserts
- Front side
- Mounting direction
- Horizontal and vertical
- Number of modules horizontal (module system)
- 2
- Number of modules vertical (module system)
- 1
- With screws
- Yes
- Flush-mounted installation
- Yes
- Material
- Plastic
- Material quality
- Thermoplastic
- Surface protection
- Untreated
- Certifications
- CE marking (EU), IMQ (Italy)
Installation switch (VM-14001.2)
- Product type
- Installation switch
- Wiring system
- Switch 1-pole
- Operating method
- Rocker/button
- Assembly arrangement
- Modular device for domestic switching devices
- Number of modules (module system)
- 2
- Push button switch
- Yes
- Number of rockers
- 1
- Mounting method
- Flush-mounted
- Type of fastening
- Engage (snap)
- Material
- Plastic
- Material quality
- Thermoplastic
- Halogen free
- Yes
- Surface protection
- Untreated
- Surface finishing
- Glossy
- Colour
- White
- RAL-number (similar)
- 9003
- Label space/information surface
- Yes
- Lighting
- Optional
- Function lighting
- Control and orientation
- Type of lighting
- LED exchangeable
- Suitable for degree of protection (IP)
- IP40
- Nominal voltage
- 250 V
- Rated current
- 16 A
- Connection type
- Screwed terminal
- Device width
- 44.8 mm
- Device height
- 49 mm
- Device depth
- 38.4 mm
- Built-in depth
- 24 mm
- Certifications
- CE marking (EU), TISI (Thailand), IMQ (Italy), RCM (Australia), TSE (Turkey), CCC (China), SASO (Saudi Arabia), WEEE Directive
Technical drawings
Downloads
FAQ
What is the current rating of the Vimar Plana Plastic 1 Gang Switch?
This parent product is rated at 16A. The rating applies across the listed child variants for this Vimar Plana 1 gang switch family.
What type of switch is this product intended for?
This is a 1 gang switch from the Vimar Plana range. It is suited to buyers looking for a white Plana-series switch for light switch and socket projects.
Are the listed child variants different in finish or warranty?
Both listed child variants are white and carry the same 3 year warranty period. The provided data does not show differences in finish colour, current rating, or warranty between the variants.
What are the dimensions of this parent product?
The parent product dimensions are 120 mm wide, 80 mm long, and 9 mm high. The listed weight is 1 kg.
Is this product part of the Vimar Plana series?
Yes, this product is categorized under Vimar Plana switch groups, including Plana 1 gang and Plana switch categories. It should be selected where the project specification calls for the Vimar Plana range and a white 1 gang switch.
What warranty period is provided for this Vimar Plana switch?
The warranty period shown for this parent product is 3 years. The same 3 year warranty is also shown on the listed child variants.
