Mean Well RQ-65D Power Supply 65W 5V 24V 12V -12
Please Login for Pricing
Description
Description
The RQ is a 125W Mean Well DIN rail power converter with a 199mm profile (input range: 176~264VAC, operating temperature: -25~+70°C).
Key Features
- ✓ 199mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 176~264VAC
- ✓ DC output voltage adjustable ±10%
- ✓ Cooling by free air convection
- ✓ Wide operating temperature: -25~+70°C
- ✓ Protections: Short circuit / Overload / Over voltage
- ✓ Safety approvals: UL62368 TUV EN62368-1, EAC TP TC 004
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesRT Series
-
Power Rating68 Watt
-
Output Voltage5 Volt
-
Rated Current4 Ampere
-
Input Voltage88V~264V
-
Standards MetCB,CE,EAC,RCM,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-25°C~70°C
-
Warranty3 Year
-
Length12.9 cm
-
Width9.8 cm
-
Height3.8 cm
-
Weight0.44 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the RQ-65D for equipment that needs 5V control power plus a higher-voltage auxiliary rail?
Yes, this quad output model is listed with 5V, 24V, 12V, and -12 outputs, so it fits designs that combine a 5V control rail with higher-voltage auxiliary rails. The main 5V output is rated at 4A and the total rated power is 68W.
Is the RQ-65D suitable for embedded automation hardware that mixes digital logic and auxiliary field circuitry?
It can be suitable when the system needs multiple rails in one supply, because the listed outputs include 5V, 24V, 12V, and -12. That combination is relevant for embedded automation assemblies that separate low-voltage logic from auxiliary circuits, within the unit's 68W total power and 5V 4A main output.
Can the RQ-65D work in compact control panels where shock or vibration is a concern?
The enclosure size is 129.0 x 98.0 x 38.0 mm and the unit weighs 0.44 kg, so it is sized for compact panel space. Its features also specify miniature size and 5G vibration resistance, which is useful in industrial cabinets and machine-mounted assemblies.
Is the RQ-65D rated for outdoor use or temperature-sensitive installations?
The specified operating temperature range is -25 degrees C to +70 degrees C, which supports a broad range of indoor operating conditions. Since no IP rating is provided in the specs, these details alone do not confirm suitability for exposed outdoor environments.
How does the RQ-65D compare to the other RQ family models in the supplied list?
The listed siblings are RQ-50B at 45.5W and 5V 5A, RQ-50C at 50W and 5V 5A, RQ-50D at 53.4W and 5V 3A, RQ-65B at 62.5W and 5V 6A, RQ-65C at 65W and 5V 5A, RQ-85B at 80.7W and 5V 7A, RQ-85C at 82.5W and 5V 7A, RQ-85D at 84W and 5V 6A, RQ-125B at 120W and 5V 11A, RQ-125C at 122.5W and 5V 10A, and RQ-125D at 124W and 5V 8A. RQ-125ND is also named as a sibling, but its electrical specs are not included in the provided list.
