Mean Well RT-50C Power Supply 50W 5V 15V -15V
Please Login for Pricing
Description
Description
The RT is a 125W Mean Well power converter (input range: 88~132VAC).
Key Features
- ✓ Input voltage range: 88~132VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3KVAC reinforced I/O isolation
- ✓ Protections: Overload / Over voltage
- ✓ Safety approvals: UL62368-1, TUV EN62368-1 , EAC TP TC 004
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesRT Series
-
Power Rating50 Watt
-
Output Voltage5 Volt
-
Rated Current4 Ampere
-
Input Voltage88V~264V
-
Standards MetCB,CE,EAC,RCM,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-25°C~70°C
-
Warranty3 Year
-
Length9.9 cm
-
Width9.7 cm
-
Height3.6 cm
-
Weight0.41 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can the RT-50C be used for industrial electronics that need both positive and negative 15V rails?
Yes, if the equipment matches the RT-50C's triple output arrangement of 5V, 15V, and -15V. The supply is rated for 50W total and provides 5V at 4A on its main listed output. That makes it more relevant for analog control and signal-processing hardware than a single-output supply.
Is the RT-50C appropriate for embedded test fixtures with logic and analog sections?
It can be a fit when the fixture needs a constant voltage source and the total load remains within 50W. The main listed output is 5V at 4A, and the model spec also includes 15V and -15V rails. That combination is useful where digital logic and analog support rails need to come from one power supply.
Can I use the RT-50C in a small instrumentation cabinet?
Yes, for lower-power instrumentation loads that fit within the 50W total rating. Its compact dimensions of 99.0 × 97.0 × 36.0 mm and weight of 0.41 kg help in tighter cabinet layouts. The 88-264VAC input also supports broad AC input compatibility.
Is the RT-50C rated for outdoor service or only for controlled enclosures?
The provided specs show an operating temperature range of -25°C to +70°C and note 5G vibration resistance, which supports demanding indoor equipment use. However, no IP rating is listed. Based on the provided data, outdoor exposure should not be assumed.
How does the RT-50C sit within the RT family lineup?
From the figures provided, the family includes RT-50A at 46.5W and 5V 4A, RT-50B at 50W and 5V 4A, RT-50C at 50W and 5V 4A, RT-50D at 51W and 5V 3A, RT-65A at 66.1W and 5V 6A, RT-65B at 64.6W and 5V 5A, RT-65C at 65.5W and 5V 5A, RT-65D at 68W and 5V 4A, RT-125A at 131W and 5V 12A, RT-125B at 132W and 5V 12A, RT-125C at 132.5W and 5V 10A, and RT-125D at 136W and 5V 8A. RT-85A, RT-85B, RT-85C, RT-85D, RT-125NA, RT-125NB, and RT-125ND are also listed without detailed specs here. RT-50C is one of the compact 50W-class models and shares the stated 5V 4A main output level with RT-50B.
