Mean Well RQ-85C Power Supply 85W 5V 15V -5V-15V
Please Login for Pricing
Description
Description
The RQ is a 125W Mean Well DIN rail power converter with a 199mm profile (input range: 176~264VAC, operating temperature: -25~+70°C).
Key Features
- ✓ 199mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 176~264VAC
- ✓ DC output voltage adjustable ±10%
- ✓ Cooling by free air convection
- ✓ Wide operating temperature: -25~+70°C
- ✓ Protections: Short circuit / Overload / Over voltage
- ✓ Safety approvals: UL62368 TUV EN62368-1, EAC TP TC 004
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesRT Series
-
Power Rating82.5 Watt
-
Output Voltage5 Volt
-
Rated Current7 Ampere
-
Input Voltage88V~264V
-
Standards MetCB,CE,EAC,RCM,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-25°C~70°C
-
Warranty3 Year
-
Length15.9 cm
-
Width9.7 cm
-
Height3.8 cm
-
Weight0.6 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the RQ-85C for control or analog equipment that needs 5V logic with +/-15V rails?
Yes, the product name lists 5V, 15V, -5V, and -15V outputs, so it is built for multi-rail applications. Its main 5V output is rated at 7A and total power is 82.5W, giving it more 5V capacity than the 65W RQ-65C version.
Is the RQ-85C a fit for embedded systems that need higher 5V current along with positive and negative auxiliary rails?
It can be a fit when the design needs a stronger 5V rail plus auxiliary positive and negative rails in one supply. This model provides 5V at 7A with 82.5W total power, and the listed outputs also include 15V, -5V, and -15V.
Can the RQ-85C be used in industrial electronics where panel space and vibration resistance matter?
The unit measures 159.0 x 97.0 x 38.0 mm and weighs 0.6 kg, which keeps the form factor fairly compact for cabinet installations. Its listed features include miniature size and 5G vibration resistance, which is relevant for industrial electronics and automation hardware.
Is the RQ-85C suitable for outdoor use or hot enclosed equipment?
The operating temperature specification is -25 degrees C to +70 degrees C, so the thermal range supports demanding indoor environments. No IP rating is provided in the supplied data, so the specs do not confirm outdoor or washdown suitability.
What are the key spec differences between the RQ-85C and the other RQ models listed?
The series list includes RQ-50B at 45.5W and 5V 5A, RQ-50C at 50W and 5V 5A, RQ-50D at 53.4W and 5V 3A, RQ-65B at 62.5W and 5V 6A, RQ-65C at 65W and 5V 5A, RQ-65D at 68W and 5V 4A, RQ-85B at 80.7W and 5V 7A, RQ-85D at 84W and 5V 6A, RQ-125B at 120W and 5V 11A, RQ-125C at 122.5W and 5V 10A, and RQ-125D at 124W and 5V 8A. RQ-125ND is also listed as a sibling, but no detailed specs are supplied for it in the provided data.
