Mean Well RQ-85D Power Supply 85W 5V 24V 12V -12
Please Login for Pricing
Description
Description
The RQ is a 125W Mean Well DIN rail power converter with a 199mm profile (input range: 176~264VAC, operating temperature: -25~+70°C).
Key Features
- ✓ 199mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 176~264VAC
- ✓ DC output voltage adjustable ±10%
- ✓ Cooling by free air convection
- ✓ Wide operating temperature: -25~+70°C
- ✓ Protections: Short circuit / Overload / Over voltage
- ✓ Safety approvals: UL62368 TUV EN62368-1, EAC TP TC 004
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesRT Series
-
Power Rating84 Watt
-
Output Voltage5 Volt
-
Rated Current6 Ampere
-
Input Voltage88V~264V
-
Standards MetCB,CE,EAC,RCM,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-25°C~70°C
-
Warranty3 Year
-
Length15.9 cm
-
Width9.7 cm
-
Height3.8 cm
-
Weight0.6 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the RQ-85D for a 5V industrial controller that also needs multiple DC rails in one chassis?
The RQ-85D is a constant-voltage power supply with quad output, and the listed specs include 5V at 6A with 84W total power. That makes it relevant for enclosed industrial or automation equipment that uses a 5V main rail and benefits from a quad-output design.
Is the RQ-85D suitable for embedded test equipment or bench electronics that run on 5V?
It can fit embedded or lab-style equipment that needs a regulated 5V constant-voltage source up to 6A. The compact 159.0 × 97.0 × 38.0 mm size and 0.6 kg weight also make it practical where internal space is limited.
Can this power supply support a 5V automation subsystem inside a machine cabinet?
It is suited to enclosed automation use where the load requires 5V constant voltage and stays within 6A and 84W. The listed features also note 5G vibration resistance and operation up to +70°C, which aligns with industrial cabinet environments.
Is the RQ-85D appropriate for indoor or outdoor environments?
The provided specs list an operating temperature range of -25°C to +70°C, but they do not list an IP rating. Based on the listed data, it is better treated as a power supply for protected indoor enclosures rather than exposed outdoor locations.
How does the RQ-85D compare with other RQ series models?
In the listed RQ family, RQ-50B is 45.5W at 5V 5A, RQ-50C is 50W at 5V 5A, RQ-50D is 53.4W at 5V 3A, RQ-65B is 62.5W at 5V 6A, RQ-65C is 65W at 5V 5A, RQ-65D is 68W at 5V 4A, RQ-85B is 80.7W at 5V 7A, RQ-85C is 82.5W at 5V 7A, and RQ-85D is 84W at 5V 6A. Higher-power listed siblings are RQ-125B at 120W 5V 11A, RQ-125C at 122.5W 5V 10A, and RQ-125D at 124W 5V 8A, while RQ-125ND is listed without power, voltage, or current details in the provided data.
