Mean Well

Mean Well HLN-80H-12A Power Supply 60W 12V - IP64, Adjustable 5A

fully isolated plastic caseIP64suitable for signage applicationsClass 2 power unit
SKU HLN-80H-12A
Log in to see price Trade pricing & online ordering for account holders
Log in or apply for a trade account →
End of Life, Succeeded by HLG-80H-12A
In stock
|

Overview

HLN-80H-12A is the 12V output model of this series: rated current 5A, rated power 60W, typical efficiency 88%.

Features

  • Universal AC input / Full range (up to 305VAC)
  • Built-in active PFC function
  • Protections: Short circuit / Over current / Over voltage / Over temperature
  • Cooling by free air convection
  • OCP point adjustable through output cable or internal potentiometer
  • Fully isolated plastic case with IP64 level
  • Class 2 power unit
  • Three in one dimming function (1~10Vdc or PWM signal or resistance)
  • Suitable for LED lighting, Industrial Lighting and moving sign applications
  • Compliance to worldwide safety regulations for lighting
  • Suitable for dry / damp locations or outdoor application
  • 3 years warranty

Specifications

HLN-80H-12ASpecifications from the official datasheet (2026-02-09 edition)

OUTPUT

DC VOLTAGE
12V
CONSTANT CURRENT REGIONNote.4
7.2 ~12V
RATED CURRENT
5A
RATED POWER
60W
RIPPLE & NOISE (max.)Note.2
150mVp-p
VOLTAGE ADJ. RANGENote.6
10.8 ~ 13.5V
CURRENT ADJ. RANGE
Can be adjusted by internal potentiometer A type only
CURRENT ADJ. RANGE
3 ~ 5A
VOLTAGE TOLERANCENote.3
±2.5%
LINE REGULATION
±0.5%
LOAD REGULATION
±2.0%
SETUP, RISE TIMENote.8
1200ms,80ms/115VAC 500ms,80ms/230VAC at full load ; B type 1200ms,200ms/115VAC 500ms,200ms/230VAC at 95% load
HOLD UP TIME (Typ.)
16ms at full load 230VAC /115VAC

INPUT

VOLTAGE RANGENote.5
90 ~ 305VAC 127 ~ 431VDC
FREQUENCY RANGE
47 ~ 63Hz
POWER FACTOR (Typ.)
PF>0.96/115VAC, PF>0.96/230VAC, PF>0.94/277VAC at full load (Please refer to "Power Factor Characteristic" curve)
TOTAL HARMONIC DISTORTION
THD< 20% when output loading≧60% at 115VAC/230VAC input and output loading≧75% at 277VAC input
EFFICIENCY (Typ.)
88%
AC CURRENT (Typ.)
0.85A / 115VAC 0.425A / 230VAC 0.4A / 277VAC
INRUSH CURRENT(Typ.)
COLD START 70A(twidth=485μs measured at 50% Ipeak) at 230VAC
MAX. No. of PSUs on 16A CIRCUIT BREAKER
3 units (circuit breaker of type B) / 6 units (circuit breaker of type C) at 230VAC
LEAKAGE CURRENT
<0.75mA / 277VAC

PROTECTION

OVER CURRENTNote.4
95 ~ 108% Protection type : Constant current limiting, recovers automatically after fault condition is removed
SHORT CIRCUIT
Hiccup mode, recovers automatically after fault condition is removed
OVER VOLTAGE
14 ~ 17V
OVER TEMPERATURE
Shut down o/p voltage, re-power on to recover

ENVIRONMENT

WORKING TEMP.
-40 ~ +50℃ (Refer to "Derating Curve")
WORKING HUMIDITY
20 ~ 95% RH non-condensing
STORAGE TEMP., HUMIDITY
-40 ~ +80℃, 10 ~ 95% RH
TEMP. COEFFICIENT
±0.03%/℃ (0 ~ 40℃)
VIBRATION
10 ~ 500Hz, 2G 12min./1cycle, period for 72min. each along X, Y, Z axes

SAFETY & EMC

SAFETY STANDARDSNote.7
UL8750, CSA C22.2 No. 250.0-08, BS EN/EN 61347-1, BS EN/EN 61347-2-13 independent ; IP64, EAC TP TC 004 approved ; Design refer to UL60950-1
WITHSTAND VOLTAGE
I/P-O/P:3.75KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC
ISOLATION RESISTANCE
I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25℃/ 70% RH
EMC EMISSION
Compliance to BS EN/EN55015, BS EN/EN61000-3-2 Class C (≧60% load, 12V model ≧65% load) ; BS EN/EN61000-3-3, EAC TP TC 020
EMC IMMUNITY
Compliance to BS EN/EN61000-4-2,3,4,5,6,8,11, BS EN/EN61547, BS EN/EN55024, light industry level (surge 4KV), criteria B, EAC TP TC 020

OTHERS

MTBF
2786.8K hrs min. Telcordia SR-332(Bellcore) ; 316.2K hrs min. MIL-HDBK-217F (25℃)
DIMENSION
181*61.5*35mm (L*W*H)
PACKING
0.5Kg; 24pcs/13Kg/0.87CUFT

Certifications & ratings

Marked features
110
Test conditions and notes13
  1. 1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25℃ of ambient temperature.
  2. 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
  3. 3. Tolerance : includes set up tolerance, line regulation and load regulation.
  4. 4. Please refer to "DRIVING METHODS OF LED MODULE".
  5. 5. Derating may be needed under low input voltages. Please check the static characteristics for more details.
  6. 6. A type only.
  7. 7. Safety and EMC design refer to EN60598-1, CNS15233, FCC part18.
  8. 8. Length of set up time is measured at cold first start. Turning ON/OFF the power supply may lead to increase of the set up time.
  9. 9. The power supply is considered as a component that will be operated in combination with final equipment. Since EMC performance will be affected by the complete installation, the final equipment manufacturers must re-qualify EMC Directive on the complete installation again. (as available on https://www.meanwell.com//Upload/PDF/EMI_statement_en.pdf)
  10. 10. To fulfill requirements of the latest ErP regulation for lighting fixtures, this LED power supply can only be used behind a switch without permanently connected to the mains.
  11. 11. The ambient temperature derating of 3.5℃/1000m with fanless models and of 5℃/1000m with fan models for operating altitude higher than 2000m(6500ft).
  12. 12. This product is not suitable for LED lighting applications in China.(It is recommended to use the LPF/NPF/XLG/XLC/XLN series in China)
  13. 13. For any application note and IP water proof function installation caution, please refer our user manual before using. https://www.meanwell.com/Upload/PDF/LED_EN.pdf

Technical drawings

HLN-80H-12A Mechanical Specification
Mechanical Specification
HLN-80H-12A Block Diagram
Block Diagram
HLN-80H-12A Derating Curve
Derating Curve
HLN-80H-12A Power Factor Characteristic
Power Factor Characteristic
HLN-80H-12A EFFICIENCY vs LOAD (48V Model)
EFFICIENCY vs LOAD (48V Model)
HLN-80H-12A H L N - 8 0 H series
H L N - 8 0 H series
HLN-80H-12A H L N - 8 0 H series (2)
H L N - 8 0 H series (2)
HLN-80H-12A DIMMING OPERATION(for B-type only)
DIMMING OPERATION(for B-type only)
HLN-80H-12A ※ Please DO NOT connect "DIM-" to "-V".
※ Please DO NOT connect "DIM-" to "-V".
HLN-80H-12A H L N - 8 0 H series
H L N - 8 0 H series
HLN-80H-12A H L N - 8 0 H series (2)
H L N - 8 0 H series (2)

Downloads

FAQ

Can I use the HLN-80H-12A for 12V LED strip lighting?

Yes, for 12V LED strip lighting where the total load stays within 60W and 5A. Because the driver's constant-current range is 7.2-12V, you should also confirm the strip is compatible with this type of output and not expecting a different power format.

Is the HLN-80H-12A suitable for 12V illuminated signage?

It can work for 12V illuminated signage when the sign load remains at or below 60W and 5A. The IP64 enclosure makes it appropriate for sign projects exposed to dust and splashing water.

Can this driver be used for 12V accent or cove lighting in exposed areas?

It can be used for 12V accent or cove lighting assemblies that need up to 60W and 5A within the 7.2-12V constant-current range. Its -40°C to +50°C operating temperature and IP64 housing support lighting in harsher indoor or semi-exposed environments.

How do I calculate maximum 12V LED strip length for the HLN-80H-12A?

Use the driver's power limit for the estimate: max strip length = 60W divided by the strip's rated watts per meter. Check your strip rated power per meter first, and confirm that the strip is suitable for a 12V constant-current driver.

How does the HLN-80H-12A compare with other HLN options?

In the HLN-80H series, models run from 12V 5A (60W) through 54V 1.5A (81W). The HLN-80H-12A is the 12V A-type option with adjustable output voltage and current at 60W and 5A, while the matching B-version keeps the same 60W, 12V, and 5A electrical rating and adds 3-in-1 dimming.
