Mean Well HLN-80H-12A Power Supply 60W 12V - IP64, Adjustable
Please Login for Pricing
Description
Description
The HLN-80H is a 80W Mean Well power converter (input range: 90~305VAC, operating temperature: -40~+50℃).
Key Features
- ✓ Input voltage range: 90~305VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -40~+50℃
- ✓ Protections: Short circuit / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: Note.7 UL8750, CSA C22.2 No. 250.0-08(except for 48V, 54V), EN61347-1, EN61347-2-13 independent ; IP64, J61347-1, J61347-2-13
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesHLN Series
-
Power Rating60 Watt
-
Output Voltage12 Volt
-
Rated Current5 Ampere
-
Input Voltage90V~305V
-
Standards MetCB,CCC,CE,EAC,PSE,TUV,UL
-
Operation ModeConstant Current,Constant Voltage
-
Operating Temperature-40°C~50°C
-
Warranty3 Year
-
Length18.1 cm
-
Width6.15 cm
-
Height3.5 cm
-
Weight0.5 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the HLN-80H-12A for 12V LED strip lighting?
Yes, for 12V LED strip lighting where the total load stays within 60W and 5A. Because the driver's constant-current range is 7-12V, you should also confirm the strip is compatible with this type of output and not expecting a different power format.
Is the HLN-80H-12A suitable for 12V illuminated signage?
It can work for 12V illuminated signage when the sign load remains at or below 60W and 5A. The IP64 enclosure and signage-oriented feature set make it appropriate for sign projects exposed to dust and splashing water.
Can this driver be used for 12V accent or cove lighting in exposed areas?
It can be used for 12V accent or cove lighting assemblies that need up to 60W and 5A within the 7-12V constant-current range. Its -40°C to +50°C operating temperature and IP64 housing support lighting in harsher indoor or semi-exposed environments.
How do I calculate maximum 12V LED strip length for the HLN-80H-12A?
Use the driver's power limit for the estimate: max strip length = 60W divided by the strip's rated watts per meter. Check your strip rated power per meter first, and confirm that the strip is suitable for a 12V constant-current driver.
How does the HLN-80H-12A compare with other HLN options?
In the HLN line, 40H models run from 12V 3.33A through 54V 0.75A, 60H models run from 15V 4A through 54V 1.15A, and 80H models run from 12V 5A through 54V 1.5A. The HLN-80H-12A is the 12V adjustable option in the 80H group at 60W and 5A, while the matching B-version keeps the same 60W, 12V, and 5A electrical rating.
