Over 15 years experience of providing support of MEAN WELL Power Supplies
Description
Description
Features
Universal AC input (up to 305VAC) / Full range |
Fully isolated plastic case with IP64 level |
Built-in active PFC function, PF> 0.9 for 60% of load or higher |
Protections: Short circuit / Over current / Over voltage / Over temperature |
Built-in constant current limiting circuit (C.V.+C.C. mode) |
Class 2 power unit / Pass LPS |
High efficiency up to 91% |
Cooling by free air convection |
Suitable for dry, damp location |
Suitable for LED lighting and moving sign applications |
Multiple models for choice: A-Type: IP64 rated. Output voltage and constant current level can be adjusted through internal potentiometer B-Type: IP64 rated and built-in 3 in 1 dimming function (1-10VDC, PWM signal, or resistance) |
3 years warranty |
General Specification
AC input voltage range | 90~305VAC; 127~431VDC |
AC inrush current (max.) | Cold start, 70A at 230VAC |
DC adjustment range | ±10% rated output voltage (A-Type only) |
Current adjustment range | 60%~100% |
Over current protection | 95%~108% constant current limiting, auto-recovery |
Over voltage protection | 109%~150% rated output voltage |
Setup, rise, hold up time | 1000ms, 80ms, 16ms at full load and 230VAC |
Withstand voltage | I/P-O/P: 3.75kVAC, I/P-FG: 2kVAC, O/P-FG:0.5kVAC |
Working temperature | -40~+50ºC (refer to output derating curve) |
Safety standards | UL8750, TUV EN61347-1, EN61347-2-13, PSE J61347-1, J61347-2-13 approved; Design refer to UL/EN60950-1, EN60335-1for |
EMC standards | EN55015, EN61000-3-2 class C, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11, EN61547 |
Connection Input | UL rated, SVT 18AWGx3C (30cm) |
Connection Output | A-Type: UL rated, SVT 18AWGx2C (30cm) ; B-Type: UL rated, SVT 18AWGx4C (30cm) |
Dimension (LxWxH) (mm) | 181x 61.5x 35 |
Specifications
Specifications
-
BrandMean Well
-
SeriesHLN Series
-
Power Rating82.8 Watt
-
Output Voltage36 Volt
-
Rated Current2.3 Ampere
-
Input Voltage90V~305V
-
Standards MetCB,CCC,CE,EAC,PSE,TUV,UL
-
Operation ModeConstant Current,Constant Voltage
-
Operating Temperature-40°C~50°C
-
Warranty3 Year
-
Length18.1 cm
-
Width6.15 cm
-
Height3.5 cm
-
Weight0.5 kg
