Mean Well SKM10A-05 DC-DC Converter - 10W - 9~18V in 5V out 2A
Log in to see priceThe SKM10A is a 10W Mean Well power converter (input range: 4.7~9Vdc).
Key Features
- ✓ Input voltage range: 4.7~9Vdc
- ✓ 1.5KVDC reinforced I/O isolation
- ✓ Protections: Short circuit / Overload / Over voltage / Under voltage
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesSKM Series
-
Power Rating10 Watt
-
Output Voltage5 Volt
-
Rated Current2 Ampere
-
Input Voltage9V~18V
-
Standards MetCE
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~85°C
-
Warranty3 Year
-
Length2.54 cm
-
Width2.54 cm
-
Height1.02 cm
-
Weight0.02 kg
::specification::
Frequently Asked Questions
Can I use the SKM10A-05 for 5V embedded systems or industrial control electronics?
Yes, this model delivers constant-voltage 5V output up to 2A with a 10W total power rating. It is intended for systems using the listed 9-18VAC input range and needing a regulated 5V supply.
Is the SKM10A-05 a good fit for 5V peripherals and controller boards inside automation equipment?
It can be used for 5V controller boards and peripherals when the load remains within 2A and 10W. Its 25.4 × 25.4 × 10.2 mm package is also compact for dense equipment layouts.
Can this converter power small 5V monitoring, interface, or sensor electronics?
It is suitable for smaller 5V electronics that require constant voltage and stay below the 2A output limit. That makes it more appropriate for low-power control and interface functions than for larger 5V loads.
Is the SKM10A-05 meant for indoor use only, or can it work in tougher environments?
The specified operating temperature range is -40°C to +85°C, so it is designed for a wide temperature window. No IP rating is listed in the product data, so the specs do not verify direct outdoor exposure.
How does the SKM10A-05 compare with the other SKM10A output models?
All listed SKM10A units are 10W constant-voltage converters with 9-18VAC input, 25.4 × 25.4 × 10.2 mm dimensions, 0.018 kg weight, and -40°C to +85°C operation. The available outputs are 3.3V at 2.5A, 5V at 2A for SKM10A-05, 12V at 833A, and 15V at 666A.
