Mean Well SKM10E-03 DC-DC Converter - 10W - 4.7~9V in 3.3V out 2.5A
Log in to see priceThe SKM10E is a 10W Mean Well power converter (input range: 4.7~9Vdc).
Key Features
- ✓ Input voltage range: 4.7~9Vdc
- ✓ 1.5KVDC reinforced I/O isolation
- ✓ Protections: Short circuit / Overload / Over voltage / Under voltage
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesSKM Series
-
Power Rating10 Watt
-
Output Voltage3.3 Volt
-
Rated Current2.5 Ampere
-
Input Voltage4.7V~9V
-
Standards MetCE
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~85°C
-
Warranty3 Year
-
Length2.54 cm
-
Width2.54 cm
-
Height1.02 cm
-
Weight0.02 kg
::specification::
Frequently Asked Questions
Can I use the SKM10E-03 for a 3.3V industrial control board or embedded controller?
It is designed for constant-voltage 3.3V output with up to 2.5A and 10W available. That makes it a fit for 3.3V control boards, embedded electronics, or low-voltage logic sections when the source is within the listed 4-9VAC input range.
Is the SKM10E-03 suitable for 3.3V sensors or data-acquisition modules in automation equipment?
This model is intended for 3.3V loads and provides a constant-voltage output rated at 2.5A. For automation or embedded sensing hardware that needs a 3.3V rail and stays within the 10W rating, it is aligned with that use case.
Can this converter support 3.3V communication or logic circuitry inside industrial equipment?
Yes, the 3.3V constant-voltage output matches common low-voltage logic and interface sections used in embedded and industrial electronics. The available output is 10W total, and the specified current is 2.5A.
Is the SKM10E-03 appropriate for outdoor or harsh-temperature equipment?
The listed operating temperature is -40°C to +85°C, which supports use across a wide temperature range. However, no IP rating is provided in the specs, so the product data does not establish suitability for exposed outdoor or washdown environments.
How does the SKM10E-03 compare with other SKM10E models?
Within the SKM10E series, all listed models are 10W parts with 4-9VAC input in the same 25.4 × 25.4 × 10.2 mm size. The difference is output: SKM10E-03 is 3.3V at 2.5A, SKM10E-05 is 5V at 2A, SKM10E-12 is 12V at 833A, and SKM10E-15 is 15V at 666A.
