Mean Well SKM10E-05 DC-DC Converter - 10W - 4.7~9V in 5V out 2A
Log in to see priceThe SKM10E is a 10W Mean Well power converter (input range: 4.7~9Vdc).
Key Features
- ✓ Input voltage range: 4.7~9Vdc
- ✓ 1.5KVDC reinforced I/O isolation
- ✓ Protections: Short circuit / Overload / Over voltage / Under voltage
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesSKM Series
-
Power Rating10 Watt
-
Output Voltage5 Volt
-
Rated Current2 Ampere
-
Input Voltage4.7V~9V
-
Standards MetCE
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~85°C
-
Warranty3 Year
-
Length2.54 cm
-
Width2.54 cm
-
Height1.02 cm
-
Weight0.02 kg
::specification::
Frequently Asked Questions
Can I use the SKM10E-05 for a 5V embedded computer or industrial controller?
This model provides a constant 5V output rated at 2A, with 10W total power. It is suitable for 5V embedded controllers or compact industrial electronics that fit within those output limits and use a 4-9VAC input source.
Is the SKM10E-05 a fit for 5V sensor hubs or interface modules in automation panels?
The unit is intended for constant-voltage 5V applications and can supply up to 2A. That makes it appropriate for 5V interface boards, sensor aggregators, or similar embedded automation loads within its 10W capacity.
Can this model be used for 5V logic or communications electronics in industrial systems?
Yes, its specified output is 5V constant voltage, which matches common logic and communications sections built around a 5V rail. The rated output current is 2A and the total output power is 10W.
Is the SKM10E-05 suitable for indoor-only use, or can it handle wider temperature conditions?
The operating temperature range is -40°C to +85°C, so the temperature spec is broad. Still, no IP rating is listed, so the published specs do not confirm suitability for outdoor exposure, water, or dust-heavy environments.
What are the output differences between the SKM10E-05 and the other SKM10E versions?
All listed SKM10E models are 10W units with 4-9VAC input and the same 25.4 × 25.4 × 10.2 mm dimensions. The outputs differ: SKM10E-03 is 3.3V at 2.5A, SKM10E-05 is 5V at 2A, SKM10E-12 is 12V at 833A, and SKM10E-15 is 15V at 666A.
