Mean Well SKM10C-12 DC-DC Converter - 10W - 36~75V in 12V out 833mA
Log in to see priceThe SKM10C is a 10W Mean Well power converter (input range: 4.7~9Vdc).
Key Features
- ✓ Input voltage range: 4.7~9Vdc
- ✓ 1.5KVDC reinforced I/O isolation
- ✓ Protections: Short circuit / Overload / Over voltage / Under voltage
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesSKM Series
-
Power Rating10 Watt
-
Output Voltage12 Volt
-
Rated Current0.83 Ampere
-
Input Voltage36V~75V
-
Standards MetCE
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~85°C
-
Warranty3 Year
-
Length2.54 cm
-
Width2.54 cm
-
Height1.02 cm
-
Weight0.02 kg
::specification::
Frequently Asked Questions
Can I use the SKM10C-12 for a 12V industrial control accessory running from a 36-75VAC source?
Yes, this model is intended for a 36-75VAC input range and provides a constant 12V output. Its 10W rating makes it suitable for lower-power 12V auxiliary electronics used in industrial and automation systems.
Is the SKM10C-12 suitable for small 12V monitoring, signaling, or control circuits in embedded equipment?
It can be a fit where the equipment needs regulated 12V power and the input source falls within 36-75VAC. Because it is rated at 10W, it is better matched to compact 12V support circuits than to larger 12V devices.
Can this converter be used for 12V subsystems inside telecom or transportation electronics?
Yes, the 36-75VAC input range makes it relevant for higher-voltage system environments, while the output remains a constant 12V. The -40°C to +85°C operating range also supports use in equipment that sees demanding temperature conditions.
Is the SKM10C-12 appropriate for exposed outdoor installations?
The temperature specification is -40°C to +85°C, which supports a wide thermal operating window. However, no IP rating is provided, so the listed specs do not confirm resistance to rain, washdown, or dust ingress for outdoor exposure.
What are the output choices across the SKM10C family if I am comparing this 12V version?
The sibling models listed are SKM10C-03 at 3.3V and 2.5A, SKM10C-05 at 5V and 2A, SKM10C-12 at 12V and 833A, and SKM10C-15 at 15V and 666A. Each is shown as a 10W model, so the comparison is mainly between the listed output voltages and output currents.
