Image shown is a representation only. Exact specifications should be obtained from the product datasheet.
Mean Well SKM10C-15 DC-DC Converter - 10W - 36~75V in 15V out 666mA
Log in to see priceThe SKM10C is a 10W Mean Well power converter (input range: 4.7~9Vdc).
Key Features
- ✓ Input voltage range: 4.7~9Vdc
- ✓ 1.5KVDC reinforced I/O isolation
- ✓ Protections: Short circuit / Overload / Over voltage / Under voltage
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesSKM Series
-
Power Rating10 Watt
-
Output Voltage15 Volt
-
Rated Current0.66 Ampere
-
Input Voltage36V~75V
-
Standards MetCE
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~85°C
-
Warranty3 Year
-
Length2.54 cm
-
Width2.54 cm
-
Height1.02 cm
-
Weight0.02 kg
::specification::
Frequently Asked Questions
Can I use the SKM10C-15 to supply 15V instrumentation or analog interface electronics from a 36-75VAC source?
Yes, this converter accepts 36-75VAC input and delivers a constant 15V output. With a 10W rating, it is suited to lower-power 15V instrumentation, analog support, or interface circuits.
Is the SKM10C-15 a fit for compact automation equipment that needs a regulated 15V rail?
It can be used in compact automation or embedded equipment where 15V constant-voltage output is required. The 25.4 × 25.4 × 10.2 mm size and 10W rating point to small auxiliary power roles rather than large 15V loads.
Can this model support 15V control electronics in high-voltage industrial or transport systems?
Yes, the 36-75VAC input range makes it appropriate where the upstream system operates at higher voltage, and the output remains a regulated 15V. Its operating temperature range of -40°C to +85°C also supports use in equipment exposed to wide temperature variation.
Is the SKM10C-15 suitable for outdoor use or washdown environments?
The product is rated for operation from -40°C to +85°C, so the thermal range is broad. However, no IP rating is listed, so the specifications do not define enclosure protection and do not by themselves support outdoor or washdown use.
How does the SKM10C-15 differ from the other SKM10C models?
The listed SKM10C family includes 3.3V at 2.5A for SKM10C-03, 5V at 2A for SKM10C-05, 12V at 833A for SKM10C-12, and 15V at 666A for SKM10C-15. All are specified as 10W converters, so the factual difference is the output voltage and the listed output current for each variant.
