Mean Well SKM10C-03 DC-DC Converter - 10W - 36~75V in 3.3V out 2.5A
Log in to see priceThe SKM10C is a 10W Mean Well power converter (input range: 4.7~9Vdc).
Key Features
- ✓ Input voltage range: 4.7~9Vdc
- ✓ 1.5KVDC reinforced I/O isolation
- ✓ Protections: Short circuit / Overload / Over voltage / Under voltage
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesSKM Series
-
Power Rating10 Watt
-
Output Voltage3.3 Volt
-
Rated Current2.5 Ampere
-
Input Voltage36V~75V
-
Standards MetCE
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~85°C
-
Warranty3 Year
-
Length2.54 cm
-
Width2.54 cm
-
Height1.02 cm
-
Weight0.02 kg
::specification::
Frequently Asked Questions
Can I use the SKM10C-03 for a 3.3V embedded controller in a high-voltage industrial system?
Yes, this model provides a constant 3.3V output and accepts a 36-75VAC input range. Its 10W rating and 2.5A listed output current make it suitable for lower-power embedded control electronics that need a regulated 3.3V rail.
Is the SKM10C-03 a good fit for powering industrial communication or logic boards that run on 3.3V?
It is appropriate for 3.3V logic or communication boards when the source available is within 36-75VAC. The unit is rated for 10W, so it fits auxiliary electronics and compact control boards rather than larger 3.3V systems with higher power demand.
Can this model support 3.3V automation electronics inside transportation or telecom equipment?
Yes, the 36-75VAC input range aligns with higher-voltage system environments, and the output is a constant 3.3V. The wide operating temperature range of -40°C to +85°C also supports use in equipment exposed to varied thermal conditions.
Is the SKM10C-03 suitable for outdoor enclosures or unprotected environments?
The operating temperature range is -40°C to +85°C, which supports broad temperature exposure. However, no IP rating is listed, so the specifications do not confirm sealing against dust or water and do not by themselves support outdoor use.
What is the difference between SKM10C-03 and the other SKM10C output versions?
The SKM10C series siblings listed are 3.3V at 2.5A for SKM10C-03, 5V at 2A for SKM10C-05, 12V at 833A for SKM10C-12, and 15V at 666A for SKM10C-15. Each is shown as a 10W model, so the listed distinction is the output voltage and corresponding output current.
