Mean Well SKM10B-03 DC-DC Converter - 10W - 18~36V in 3.3V out 2.5A
Log in to see priceThe SKM10B is a 10W Mean Well power converter (input range: 4.7~9Vdc).
Key Features
- ✓ Input voltage range: 4.7~9Vdc
- ✓ 1.5KVDC reinforced I/O isolation
- ✓ Protections: Short circuit / Overload / Over voltage / Under voltage
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesSKM Series
-
Power Rating10 Watt
-
Output Voltage3.3 Volt
-
Rated Current2.5 Ampere
-
Input Voltage18V~36V
-
Standards MetCE
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~85°C
-
Warranty3 Year
-
Length2.54 cm
-
Width2.54 cm
-
Height1.02 cm
-
Weight0.02 kg
::specification::
Frequently Asked Questions
Can I use the SKM10B-03 for 3.3V logic in industrial or automation equipment with an 18-36VAC source?
Yes, this model is intended for 18-36VAC input and provides a constant 3.3V output. With a 10W rating and 2.5A output current, it fits low-power logic and control sections that need regulated 3.3V from that input range.
Is the SKM10B-03 suitable for embedded controllers that need 3.3V in a very small footprint?
It is compact at 25.4 × 25.4 × 10.2 mm and weighs 0.018 kg, which helps in space-constrained embedded builds. The constant 3.3V output is appropriate for embedded controller sections that stay within 10W and 2.5A.
Can the SKM10B-03 be used in systems that see high and low ambient temperatures?
The operating temperature range is -40°C to +85°C, so it is specified for wide-temperature operation. That makes it relevant for industrial and embedded equipment installed in environments with large ambient variation.
Is this converter appropriate for outdoor use?
The specs give a temperature range of -40°C to +85°C, but they do not list an IP rating. Without an IP rating, it should be treated as a converter for protected indoor or enclosure-mounted use rather than direct outdoor exposure.
How does the SKM10B-03 compare with the other SKM10B versions?
The SKM10B series shown here keeps the same 10W format and 18-36VAC input class while changing output ratings. The siblings listed are 3.3V at 2.5A, 5V at 2A, 12V at 833A, and 15V at 666A.
