Mean Well SKM10B-05 DC-DC Converter - 10W - 18~36V in 5V out 2A
Log in to see priceThe SKM10B is a 10W Mean Well power converter (input range: 4.7~9Vdc).
Key Features
- ✓ Input voltage range: 4.7~9Vdc
- ✓ 1.5KVDC reinforced I/O isolation
- ✓ Protections: Short circuit / Overload / Over voltage / Under voltage
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesSKM Series
-
Power Rating10 Watt
-
Output Voltage5 Volt
-
Rated Current2 Ampere
-
Input Voltage18V~36V
-
Standards MetCE
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~85°C
-
Warranty3 Year
-
Length2.54 cm
-
Width2.54 cm
-
Height1.02 cm
-
Weight0.02 kg
::specification::
Frequently Asked Questions
Can I use the SKM10B-05 for a 5V industrial control or automation load from 18-36VAC?
Yes, it accepts 18-36VAC input and provides a constant 5V output. Its 10W power rating and 2A output current make it suitable for low-power 5V control and automation electronics within those limits.
Is the SKM10B-05 a fit for embedded 5V electronics in compact equipment?
It is small at 25.4 × 25.4 × 10.2 mm and light at 0.018 kg, which supports dense embedded layouts. The regulated 5V output is useful where the embedded load fits inside the 10W and 2A ratings.
Can this converter be used in equipment installed in unheated or hot industrial spaces?
The specified operating temperature range is -40°C to +85°C. That allows use in equipment that must handle cold starts or elevated ambient conditions, provided the application also matches the 18-36VAC input and 10W output rating.
Is the SKM10B-05 suitable for outdoor or damp locations?
Its temperature range is broad at -40°C to +85°C, but no IP rating is listed in the published specs. Because ingress protection is not stated, it is better applied inside a protected enclosure rather than in exposed damp or outdoor locations.
What changes across the SKM10B series if I am comparing output options?
The main change across the listed SKM10B models is the output rating, while each remains a 10W converter. The sibling outputs are 3.3V at 2.5A, 5V at 2A, 12V at 833A, and 15V at 666A.
