Mean Well SKM10C-05 DC-DC Converter - 10W - 36~75V in 5V out 2A
Log in to see priceThe SKM10C is a 10W Mean Well power converter (input range: 4.7~9Vdc).
Key Features
- ✓ Input voltage range: 4.7~9Vdc
- ✓ 1.5KVDC reinforced I/O isolation
- ✓ Protections: Short circuit / Overload / Over voltage / Under voltage
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesSKM Series
-
Power Rating10 Watt
-
Output Voltage5 Volt
-
Rated Current2 Ampere
-
Input Voltage36V~75V
-
Standards MetCE
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~85°C
-
Warranty3 Year
-
Length2.54 cm
-
Width2.54 cm
-
Height1.02 cm
-
Weight0.02 kg
::specification::
Frequently Asked Questions
Can I use the SKM10C-05 to power a 5V industrial controller or data-logging board from a 36-75VAC source?
Yes, this converter accepts 36-75VAC input and provides a constant 5V output. With a 10W rating and 2A listed output current, it fits lower-power 5V control and monitoring electronics.
Is the SKM10C-05 suitable for 5V sensor-processing or interface electronics in automation equipment?
It can be used where a regulated 5V rail is needed for auxiliary automation electronics and the available source is within 36-75VAC. The 10W power level makes it more appropriate for small interface, sensing, or logic sections than for larger 5V subsystems.
Can this model be used in embedded systems that need 5V support power in a compact space?
Yes, the 25.4 × 25.4 × 10.2 mm dimensions support compact designs that need a constant 5V output. Its 10W rating suits small embedded assemblies, service processors, or control daughterboards rather than high-power 5V loads.
Does the SKM10C-05 work for indoor panels with wide temperature swings?
The specified operating temperature range is -40°C to +85°C, so it is suited to applications with substantial indoor temperature variation. No IP rating is listed, so the specs do not define protection against water or dust exposure.
How does SKM10C-05 compare with the other SKM10C series models?
The listed SKM10C siblings are 3.3V at 2.5A for SKM10C-03, 5V at 2A for SKM10C-05, 12V at 833A for SKM10C-12, and 15V at 666A for SKM10C-15. All are 10W converters, so the factual difference across the family is the output voltage and output current shown for each version.
