Mean Well RDDW20H-12 DC-DC Converter - 20W - 43~160V in ±12V out 1.83A
Log in to see priceThe RDDW20H is a 20W Mean Well power converter (input range: 9~36Vdc).
Key Features
- ✓ Input voltage range: 9~36Vdc
- ✓ Protections: Short circuit / Overload / Over voltage / Under voltage
- ✓ Railway standards: EN45545-2 (fire), EN50155 / IEC60571, IEC61373 (shock & vibration)
- ✓ Remote ON/OFF control
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesRSD Series
-
Power Rating20 Watt
-
Output Voltage12 Volt
-
Rated Current1.83 Ampere
-
Input Voltage43V~160V
-
Standards MetCB,CE,EAC,EMC,RCM
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~85°C
-
Warranty3 Year
-
Length5.08 cm
-
Width2.54 cm
-
Height1.02 cm
-
Weight0.04 kg
::specification::
Frequently Asked Questions
Can I use the RDDW20H-12 for ±12V analog stages in industrial automation equipment?
Yes. It provides dual ±12V constant-voltage output with 20W total power, which fits low-power analog stages such as signal conditioning, instrumentation, and control-card support rails. Its -40°C to +85°C operating range also aligns with industrial temperature requirements.
Is the RDDW20H-12 suitable for embedded control boards that need split ±12V power?
It is intended for designs that specifically need dual ±12V rails rather than a single-output supply. The 20W rating and 50.8 × 25.4 × 10.2 mm size make it practical for compact embedded hardware where board space is limited.
Can this model be used for PLC or machine-control analog interface sections?
Yes, for low-power analog interface sections designed around ±12V constant-voltage input. The 20W output is appropriate for control electronics and interface circuitry, not for higher-power loads.
Is the RDDW20H-12 appropriate for harsh indoor environments with vibration?
The product features include 5G vibration resistance, and the operating temperature range is -40°C to +85°C. That supports use in industrial equipment installed in protected indoor enclosures where vibration and temperature variation are expected.
What is the difference between the RDDW20H-12 and RDDW20H-15?
Both are 20W converters in the same series with 43-160VAC input. The RDDW20H-12 provides 12V output at 1.83A, while the RDDW20H-15 provides 15V output at 667A. The main selection point is the output voltage requirement.
