Mean Well GC30B-4P1J Portable Chargers 30W 14.3V 2.09A - Green Adaptor
Please Login for Pricing
Description
Description
The GC30B is a 30W Mean Well power converter (input range: 5~5.8V).
Key Features
- ✓ Input voltage range: 5~5.8V
- ✓ 3KVAC reinforced I/O isolation
- ✓ Protections: Overload / Over voltage / Over temperature
- ✓ Safety approvals: UL60950-1, CSA22.2, EN60950-1
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesGC Series
-
Power Rating30 Watt
-
Output Voltage14.3 Volt
-
Rated Current2.09 Ampere
-
Input Voltage90V~264V
-
Standards MetCB,CE,cUL,EAC,FCC,TUV
-
Operation ModeConstant Voltage
-
Operating Temperature0°C~50°C
-
Warranty2 Year
-
Length10.8 cm
-
Width6.7 cm
-
Height3.6 cm
-
Weight0.31 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
What is the Mean Well GC30B-4P1J used for?
The GC30B-4P1J is a 30W portable charger and power adaptor designed for lead-acid batteries, including flooded, gel, and AGM types. It is also specified for certain Li-ion battery chemistries, including lithium iron and lithium manganese. This makes it suitable for buyers looking for a compact charger for battery-powered equipment that needs 14.3V output.
What are the main electrical ratings of the GC30B-4P1J?
This model is rated at 30W with a 14.3V DC output and 2.09A rated current. It operates with constant current and constant voltage charging modes. The input range is universal at 90 to 264VAC or 127 to 370VDC.
Is the GC30B-4P1J suitable for portable or space-limited equipment?
Yes. The charger has a compact enclosed plastic case measuring 108 x 67 x 36 mm and weighs 309 g. Its portable form factor makes it a practical choice where a small external charger or adaptor is preferred.
What protection features are included in this charger?
The GC30B-4P1J includes short circuit, overload, over-voltage, and over-temperature protection. Its over-voltage protection shuts down and latches off the output, with recovery after re-powering. These protections help support reliable operation in demanding commercial or industrial use.
Can this model be used in different countries or with varying AC mains input?
Yes. It supports universal AC input from 90 to 264VAC, which makes it suitable for use across regions with different standard mains voltages. It also accepts 127 to 370VDC input, adding flexibility for certain DC-powered environments.
What operating environment is the GC30B-4P1J designed for?
This model is specified for operation from 0°C to 50°C, subject to the stated derating curve. It is built in a fully enclosed plastic case and is intended for continued load use. That makes it appropriate for indoor commercial and industrial environments within its rated temperature range.
How can buyers tell the charging status on this model?
The GC30B-4P1J includes a 2-color LED indicator for charging status. This gives a simple visual reference during operation without needing additional monitoring hardware. It is a useful feature for portable and everyday charging applications.
What certifications and warranty does the GC30B-4P1J include?
This model lists approvals including TUV, UL, CUL, CB, FCC, and CE, and it also cites UL62368-1 and CSA22.2 safety standards. EMC compliance includes EN55022 Class B and FCC Part 15 Class B among other standards. The unit is backed by a 2-year warranty.
