Mean Well GC30B-5P1J Portable Chargers 27W 16.8V 1.6A - Green Adaptor
Please Login for Pricing
Description
Description
The GC30B is a 30W Mean Well power converter (input range: 5~5.8V).
Key Features
- ✓ Input voltage range: 5~5.8V
- ✓ 3KVAC reinforced I/O isolation
- ✓ Protections: Overload / Over voltage / Over temperature
- ✓ Safety approvals: UL60950-1, CSA22.2, EN60950-1
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesGC Series
-
Power Rating27 Watt
-
Output Voltage16.8 Volt
-
Rated Current1.6 Ampere
-
Input Voltage90V~264V
-
Standards MetCB,CE,cUL,EAC,FCC,TUV
-
Operation ModeConstant Voltage
-
Operating Temperature0°C~50°C
-
Warranty2 Year
-
Length10.8 cm
-
Width6.7 cm
-
Height3.6 cm
-
Weight0.31 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
What type of battery charger is the Mean Well GC30B-5P1J?
The GC30B-5P1J is a 27W portable charger with a 16.8V output and 1.6A rated current. It is designed for charging supported battery types using constant current and constant voltage operation, and it includes a 2-color LED charging status indicator.
Which battery chemistries is the GC30B-5P1J intended for?
This model is listed for lead-acid batteries including flooded, gel, and AGM types. It is also described as suitable for certain lithium-ion battery chemistries, including lithium iron and lithium manganese variants.
Is the GC30B-5P1J suitable for portable or field-use equipment?
Yes. This is a portable charger in a fully enclosed plastic case, and its compact 108 x 67 x 36 mm size supports use where space and portability matter. Its Class II design and universal AC input also make it practical for varied business environments.
What protection features are included on the GC30B-5P1J?
The GC30B-5P1J includes protection for short circuit, overload, over voltage, and over temperature conditions. The over-voltage function shuts down and latches off the output, with recovery requiring power to be reapplied.
What input range and operating temperature does this charger support?
This model accepts a universal AC input range of 90 to 264VAC and also supports 127 to 370VDC input. Its specified working temperature range is 0 to 50 degrees C, with derating referenced by the manufacturer.
Does the GC30B-5P1J meet common safety and EMC approvals?
Yes. The product description lists approvals including TUV, UL, CUL, CB, FCC, and CE, and the general specification cites UL62368-1, CSA22.2, and EAC TP TC 004 safety standards. EMC standards listed include EN55022 Class B and FCC Part 15 Class B, among others.
