Mean Well GC30E-4P1J Portable Chargers 30W 14.3V 2.09A - Green Adaptor
Please Login for Pricing
Description
Description
The GC30E is a 30W Mean Well power converter (input range: 3.6~4.4V).
Key Features
- ✓ Input voltage range: 3.6~4.4V
- ✓ 3KVAC reinforced I/O isolation
- ✓ Protections: Overload / Over voltage / Over temperature
- ✓ Safety approvals: EN60950-1
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesGC Series
-
Power Rating30 Watt
-
Output Voltage14.3 Volt
-
Rated Current2.09 Ampere
-
Input Voltage90V~264V
-
Standards MetCB,CE,EAC,FCC,TUV
-
Operation ModeConstant Voltage
-
Operating Temperature0°C~50°C
-
Warranty2 Year
-
Length10.8 cm
-
Width6.7 cm
-
Height3.6 cm
-
Weight0.41 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
What is the Mean Well GC30E-4P1J designed for?
The GC30E-4P1J is a 30W portable charger intended for lead-acid batteries, including flooded, gel, and AGM types, as well as certain lithium-ion battery chemistries noted by the manufacturer. It provides a 14.3V output at up to 2.09A. This makes it suitable for battery charging applications that match those output requirements.
What are the key electrical ratings of the GC30E-4P1J?
This model is rated for 30W output with a nominal output of 14.3V DC and 2.09A. It accepts a universal AC input range of 90 to 264VAC, and also supports 127 to 370VDC input. The charger operates in constant current and constant voltage modes.
Is the GC30E-4P1J suitable for portable or field use?
Yes, this model is built in a fully enclosed plastic case and is described as a portable charger. Its compact dimensions of 108 x 67 x 36 mm and approximate weight of 405g make it easier to handle and transport than larger industrial chargers. It also includes a Euro type 6-foot 2-pin power cord.
What operating environment is the GC30E-4P1J rated for?
The specified working temperature range is 0°C to 50°C, with derating referenced by the manufacturer. This makes it appropriate for indoor and similar controlled-use environments within that temperature window. Buyers should confirm their application stays within the stated thermal limits.
What protections are included in the GC30E-4P1J?
The GC30E-4P1J includes protection for short circuit, overload, over-voltage, and over-temperature conditions. Its over-voltage protection is specified at 110% to 135%, with shutdown and latch-off behavior until power is reapplied. These features help protect both the charger and the connected load during abnormal conditions.
How can I tell the charging status on this model?
This charger includes a 2-color LED indicator for charging status. That provides a quick visual status reference without needing external monitoring equipment. For buyers comparing portable chargers, this is a useful built-in status feature.
What approvals and warranty come with the GC30E-4P1J?
The product description lists approvals including TUV, UL, CUL, CB, FCC, and CE, and the general specification also references UL62368-1, CSA22.2, and EAC TP TC 004 approval. EMC compliance includes standards such as EN55022 Class B and FCC Part 15 Class B. The listed warranty period for this model is 2 years.
