Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Boxco

Boxco Q-Series 210×210×130mm Plastic Enclosure, IP67, IK08, ABS, Transparent Cover, Plastic Hinge and Latch Type

SKU BC-ATQ-212113
Log in to see price Trade pricing & online ordering for account holders
Log in or apply for a trade account →
In stock
|

Overview

BC-ATQ-212113 is a 210×210×130 mm ABS enclosure with a transparent cover from the Boxco Q Series.

Features

  • BOXCO electrical juntion box include plastic latch and plastic hinge.
  • Our IP66/IP67 waterproof control box is easy to removable cover and body
  • AGQ series is included G plate.**Dimensions and specifications are subject to change without notice.

Specifications

BC-ATQ-212113Specifications from the official datasheetDownload datasheet PDF

Dimensions

Size W × L × H (cover included)
210×210×130 mm (8.27×8.27×5.12 in)
Mounting plate dimension M1 × M2
180 × 180 mm

Material

Material
ABS
Cover
Transparent
Mounting plates
2020 G (Plastic, G type), 2020 SQ (Steel, SQ type)

Protection & environment

IP rating
IP66/67
IK rating
IK08
Operating temperature
-40 ~ +70℃
Flammability rating (UL 94)
94-HB
Test conditions and notes1
  1. Dimensions and specifications are subject to change without notice.

Downloads

FAQ

What are the dimensions of the Boxco Q-Series BC-ATQ-212113 enclosure?

This enclosure measures 8.27 x 8.27 x 5.12 inches, which corresponds to 210 x 210 x 130 mm. It is part of the Boxco Q-Series plastic enclosure line and is sized for applications that need a compact but relatively deep housing.

What material is this enclosure made from?

The BC-ATQ-212113 is made from ABS plastic and includes a transparent cover. The product description also notes anti-static material and ultraviolet stabilizer support, which helps protect sensitive equipment and improves outdoor durability.

Is this enclosure suitable for outdoor environments?

Yes, this model is designed for demanding environments and includes UV stabilizer for outdoor use. It is rated IP67 for dust and water resistance, and the roof protection design helps reduce water and dust penetration during cover operation.

How durable is this plastic enclosure against impact?

This model carries an IK08 impact rating, indicating good resistance to external mechanical impact. The description also highlights high impact resistant material intended to reduce breakage during processing and use.

What operating temperature range does this enclosure support?

The specified operating temperature range is -40°C to 70°C. That makes this enclosure suitable for a wide range of industrial and outdoor applications where low or elevated ambient temperatures are a concern.

What types of applications is this Boxco enclosure commonly used for?

This enclosure is suited for protecting electronic instruments and other components that need a sealed plastic housing. Its anti-static material, transparent cover, and internal mounting features make it a practical choice for industrial, control, and outdoor equipment protection.

What design features distinguish this Q-Series enclosure from a basic plastic box?

This model includes a transparent cover, plastic hinge and latch construction, pre-molded mounting screw nuts, gasket sealing, and dedicated mounting plate attachment points. Compared with a basic enclosure, these features support stronger environmental protection and better internal equipment mounting.
