Boxco M-Series 130x130x35mm Plastic Enclosure, IP67, IK08, ABS, Gre...
Please Login for Pricing
Description
Description
For Boxco M-Series, Ultraviolet Stabilizer is added to protect the enclosures for outdoor usage. Few colour changes will be noticed even after a long time of use. Anti-static material is used to protect sensitive electronic instruments from static electricity. It is made of high impact resistant material which is very strong against external impact and also prevents breakage during hole and press processing. Special spec can be added besides standard specification. We can supply optimized products with the spec and material you choose.
Features
- Screw type with recessed cover
- Used for mounting membrane keypad
Specifications
Specifications
-
BrandBoxco
-
SeriesBoxco M Series
-
Standards MetCE,TUV,UL
-
Operating Temperature-40°C~70°C
-
Warranty1 Year
-
Length13 cm
-
Width13 cm
-
Height3.5 cm
-
Weight0.18 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
What are the main specifications of the Boxco M-Series BC-AGM-131303 enclosure?
This model is a screw-type plastic enclosure with a grey cover and overall dimensions of 5.12 x 5.12 x 1.38 inches (130 x 130 x 35 mm). It is made from ABS, rated IP67 for dust and water protection, and rated IK08 for impact resistance. The enclosure weighs 0.176 kg.
Is the BC-AGM-131303 suitable for outdoor use?
Yes, this Boxco M-Series enclosure is described as having an ultraviolet stabilizer added to help protect it in outdoor usage. The product description notes that only small color changes are expected even after long-term use. Its IP67 rating also supports use in demanding environments where dust and water exposure are concerns.
What types of applications is this enclosure commonly used for?
This enclosure is intended for protecting electronic components and sensitive instruments in industrial or commercial applications. The product description specifically notes anti-static material for sensitive electronic instruments and says the recessed screw cover is used for mounting a membrane keypad. It is a practical choice where compact protection and durability are important.
What does the IP67 and IK08 rating mean for this model?
For this specific enclosure, the IP67 rating indicates a high level of protection against dust and water ingress. The IK08 rating indicates resistance to external mechanical impact. Together, these ratings make the BC-AGM-131303 a strong option for environments where both sealing and toughness matter.
What temperature range can the BC-AGM-131303 handle?
This model is specified for operation from -40 degrees C to 70 degrees C. That range supports use in both low-temperature and moderately high-temperature environments. Buyers should confirm the full system requirements, but the enclosure itself is rated within that span.
Does this enclosure support keypad-style designs or custom specifications?
Yes, the product description states that the screw-type enclosure has a recessed cover used for mounting a membrane keypad. It also notes that special specifications can be added beyond the standard specification. That makes this model suitable for buyers evaluating standard enclosures with potential customization options.
