Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Boxco

Boxco S-Series 80×110×85mm Plastic Enclosure, IP67, IK08, ABS, Transparent Cover, Screw Type

SKU BC-ATS-081108-K
Log in to see price Trade pricing & online ordering for account holders
Log in or apply for a trade account →
Available to order
|

Overview

BC-ATS-081108-K is a 80×110×85 mm ABS enclosure with a transparent cover from the Boxco K Series.

Features

  • BOXCO waterproof IP66/IP67 plastic enclosures have knockouts on both sides so it is easy to punch holes. 2. Our knock-outs enclosures are easy to make onsite installation of cable or wiring. 3. This series are made for electrical control box, junction box and many other applications.

Specifications

BC-ATS-081108-KSpecifications from the official datasheetDownload datasheet PDF

Dimensions

Size W × L × H (cover included)
80×110×85 mm (3.15×4.33×3.35 in)

Material

Material
ABS
Cover
Transparent

Protection & environment

IP rating
IP66/67
IK rating
IK08
Operating temperature
-40 ~ +70℃
Flammability rating (UL 94)
94-HB
Test conditions and notes1
  1. Dimensions and specifications are subject to change without notice.

Technical drawings

BC-ATS-081108-K Dimensions (mm)
Dimensions (mm)

Downloads

FAQ

What type of enclosure is the Boxco S-Series BC-ATS-081108-K?

This model is a plastic enclosure box made from ABS with a transparent cover and a screw-type closure. Its listed dimensions are 3.15 x 4.33 x 3.35 inches (80 x 110 x 85 mm), making it a compact option for protecting components in enclosed applications.

What do the IP67 and IK08 ratings mean for this enclosure?

The BC-ATS-081108-K is rated IP67, which indicates strong protection against dust and temporary immersion exposure. It also carries an IK08 impact rating, showing it is designed to withstand a meaningful level of mechanical impact for demanding environments.

Does this enclosure have a clear cover for visual inspection?

Yes, this model includes a transparent cover. That makes it useful when users want to view labels, indicators, or internal components without choosing an opaque lid version.

What environments is this enclosure suited for?

This enclosure is specified for operating temperatures from -40 °C to 70 °C, which supports use across cold and moderately hot conditions. Combined with its IP67 and IK08 ratings, it is suited to industrial and commercial settings where protection from dust, water exposure, and impact matters.

What kinds of applications is this Boxco enclosure typically used for?

This model is typically considered for applications that need a compact protected housing for enclosed electrical or control components. Buyers often look at this style of enclosure when they need a screw-type ABS box with a clear cover and strong environmental protection in a small footprint.

Does this model include any base features that help with enclosure selection?

Yes, the product description states that this S-Series enclosure has a knock out base. For buyers comparing similar housings, that is a distinguishing feature to confirm when selecting a model for a broader enclosure family.
