Boxco

Boxco S-Series 125×175×100mm Plastic Enclosure, IP67, IK08, ABS, Grey Cover, Screw Type

SKU BC-AGS-121710-K
Log in to see price Trade pricing & online ordering for account holders
Log in or apply for a trade account →
Available to order
|

Overview

BC-AGS-121710-K is a 125×175×100 mm ABS enclosure with a grey cover from the Boxco K Series.

Features

  • BOXCO waterproof IP66/IP67 plastic enclosures have knockouts on both sides so it is easy to punch holes. 2. Our knock-outs enclosures are easy to make onsite installation of cable or wiring. 3. This series are made for electrical control box, junction box and many other applications.

Specifications

BC-AGS-121710-KSpecifications from the official datasheetDownload datasheet PDF

Dimensions

Size W × L × H (cover included)
125×175×100 mm (4.92×6.89×3.94 in)
Mounting plate dimension M1 × M2
110 × 159 mm

Material

Material
ABS
Cover
Grey
Mounting plates
1217 G (Plastic, G type), 1217 P (Plastic, P type), 1217 S (Steel, S type)

Protection & environment

IP rating
IP66/67
IK rating
IK08
Operating temperature
-40 ~ +70℃
Flammability rating (UL 94)
94-HB
Test conditions and notes1
  1. Dimensions and specifications are subject to change without notice.

Technical drawings

BC-AGS-121710-K Dimensions (mm)
Dimensions (mm)

Downloads

FAQ

What are the dimensions of the Boxco S-Series BC-AGS-121710-K enclosure?

This model measures 4.92 x 6.89 x 3.94 inches, which is 125 x 175 x 100 mm. Those dimensions make it a mid-sized plastic enclosure within the S-Series range.

What material and cover style does this enclosure use?

The BC-AGS-121710-K is made from ABS plastic and comes with a grey cover. It is a screw type enclosure, which is part of how this specific model is identified in the product name and feature set.

What environmental protection ratings does this enclosure have?

This enclosure is rated IP67 and IK08. That means this specific model is designed for strong ingress protection and impact resistance appropriate to those published ratings.

What temperature range is this enclosure rated for?

The published operating temperature range for this model is -40 degrees C to 70 degrees C. That range supports use in both cold and warm industrial or commercial environments within those limits.

Does this Boxco enclosure include a knock out base?

Yes, the product description states that this S-Series model has a knock out base. That is one of the listed features for the BC-AGS-121710-K.

What kinds of applications is this enclosure suited for?

This model is suited for protecting components in applications that need a durable plastic enclosure with IP67 and IK08 ratings. Buyers often consider this type of enclosure when they need a screw cover design, ABS construction, and a defined temperature range for industrial or commercial use.
