Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Boxco

Boxco S-Series 125×175×75mm Plastic Enclosure, IP67, IK08, ABS, Grey Cover, Screw Type

SKU BC-AGS-121707-K
Log in to see price Trade pricing & online ordering for account holders
Log in or apply for a trade account →
Available to order
|

Overview

BC-AGS-121707-K is a 125×175×75 mm ABS enclosure with a grey cover from the Boxco K Series.

Features

  • BOXCO waterproof IP66/IP67 plastic enclosures have knockouts on both sides so it is easy to punch holes. 2. Our knock-outs enclosures are easy to make onsite installation of cable or wiring. 3. This series are made for electrical control box, junction box and many other applications.

Specifications

BC-AGS-121707-KSpecifications from the official datasheetDownload datasheet PDF

Dimensions

Size W × L × H (cover included)
125×175×75 mm (4.92×6.89×2.95 in)
Mounting plate dimension M1 × M2
110 × 159 mm

Material

Material
ABS
Cover
Grey
Mounting plates
1217 G (Plastic, G type), 1217 P (Plastic, P type), 1217 S (Steel, S type)

Protection & environment

IP rating
IP66/67
IK rating
IK08
Operating temperature
-40 ~ +70℃
Flammability rating (UL 94)
94-HB
Test conditions and notes1
  1. Dimensions and specifications are subject to change without notice.

Technical drawings

BC-AGS-121707-K Dimensions (mm)
Dimensions (mm)

Downloads

FAQ

What is this enclosure typically used for?

This Boxco S-Series plastic enclosure is typically used to protect electrical or electronic components in industrial and commercial environments. Its screw-type design and IP67 protection make it a practical choice for applications where dust resistance and protection against temporary water exposure matter.

What are the dimensions of this enclosure?

This model measures 4.92 x 6.89 x 2.95 inches, which is also listed as 125 x 175 x 75 mm. These dimensions make it suitable for projects that need a compact but usable internal housing size.

What material is this enclosure made from?

This enclosure is made from ABS plastic and includes a grey cover. ABS is commonly chosen for enclosures because it provides a good balance of durability and light weight for general-purpose industrial use.

Is this enclosure suitable for dusty or wet environments?

Yes, this model is rated IP67, which means it is designed to resist dust ingress and temporary immersion in water under rated conditions. That makes it a strong option for demanding environments where contamination or moisture exposure is a concern.

How durable is this enclosure against impact?

This enclosure carries an IK08 impact rating. That indicates it offers solid mechanical protection for enclosed components in environments where incidental impacts may occur.

What temperature range can this enclosure handle?

This model is specified for use from -40 degrees C to 70 degrees C. That wide operating range supports use in both cold and moderately hot environments, depending on the overall application requirements.

Does this enclosure have any feature for cable or access entry points?

Yes, the product description states that this series has a knock out base. Buyers who need an enclosure family with that base feature may find this model appropriate for their enclosure selection criteria.
