Boxco S-Series 125×175×75mm Plastic Enclosure, IP67, IK08, ABS, Transparent Cover, Screw Type

This model is a plastic enclosure with ABS construction, a transparent cover, and a screw-type closure. Its external size is 4.92 x 6.89 x 2.95 inches, which is 125 x 175 x 75 mm. It is rated IP67 and IK08, weighs 0.5000 kg, and has an operating temperature range of -40 °C to 70 °C.

This enclosure carries an IP67 rating, which indicates strong protection against dust ingress and temporary immersion conditions. That makes it a solid choice for demanding industrial or outdoor environments where moisture and dust resistance matter. Buyers should still confirm that the full assembly maintains the required protection level for the end application.

The transparent cover allows visual inspection of indicators, labels, or internal components without opening the enclosure. That can be useful in applications where quick status checks are needed while keeping the box closed. For this specific model, the transparent cover is part of the standard configuration.

This model uses a screw-type cover, which is typically chosen when a more secure closure is preferred. Compared with quick-access styles, a screw-fastened cover is generally better suited to applications where the enclosure should remain firmly closed during regular operation. For BC-ATS-121707-K, the screw-type design is one of the listed features.

Yes, this model is specified for temperatures from -40 °C up to 70 °C. That range supports use in many indoor and outdoor industrial environments with significant temperature variation. It is important to evaluate the full system, since internal components may have narrower temperature limits than the enclosure itself.

Yes, the product description states that this S-Series enclosure has a knockout base. That feature can be relevant for buyers looking for flexibility in enclosure preparation while selecting the box style. The knockout-base detail is specific to this model's listed features.

With its IP67 rating, IK08 impact rating, ABS construction, and transparent screw-fastened cover, this model is suited to protecting controls or components in general industrial enclosure applications. It is especially relevant where dust resistance, moisture protection, and visual access through the lid are useful. The 125 x 175 x 75 mm size also makes it appropriate when a mid-sized enclosure format is needed.

The listed warranty period for this model is 1 year. That applies specifically to the BC-ATS-121707-K product data provided here. Buyers comparing enclosure options can use that as part of their evaluation alongside material, environmental, and impact ratings.
