Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Boxco

Boxco S-Series 80x110x85mm Plastic Enclosure, IP67, IK08, ABS, Transparent Cover, Screw Type

SKU BC-ATS-081108
Log in to see price Trade pricing & online ordering for account holders
Log in or apply for a trade account →
In stock
|

Overview

BC-ATS-081108 is a 80×110×85 mm ABS enclosure with a transparent cover from the Boxco S Series.

Features

  • S series enclosure's screw thread of the base for connecting cover is molded so that it has sufficient strength and not broken
  • Our electrical junction box is designed as 4 side sliding type to be strong against impact.
  • BOXCO's terminal box is suitable for mounting electrical components and it is available in ABS and polycarbonate.

Specifications

BC-ATS-081108Specifications from the official datasheetDownload datasheet PDF

Dimensions

Size W × L × H (cover included)
80×110×85 mm (3.15×4.33×3.35 in)
Mounting plate dimension M1 × M2
65 × 95 mm

Material

Material
ABS
Cover
Transparent
Mounting plates
0811 P (Plastic, P type), 0811 S (Steel, S type)

Protection & environment

IP rating
IP66/67
IK rating
IK08
Operating temperature
-40 ~ +70℃
Flammability rating (UL 94)
94-HB
Test conditions and notes1
  1. Dimensions and specifications are subject to change without notice.

Technical drawings

BC-ATS-081108 Dimensions (mm)
Dimensions (mm)

Downloads

FAQ

What applications is the Boxco S-Series BC-ATS-081108 enclosure suited for?

This model is suited for protecting sensitive electronics and control components in indoor or outdoor industrial environments where dust and water resistance matter. Its anti-static ABS construction, transparent cover, and compact 80 x 110 x 85 mm size make it a practical choice for enclosed monitoring, control, or instrumentation assemblies.

Can this plastic enclosure be used outdoors?

Yes. The product description states that an ultraviolet stabilizer is added for outdoor usage, helping reduce visible color change over long periods of exposure. Its IP67 rating also supports use in demanding environments where protection against dust and water ingress is important.

What are the key protection and material specs for this enclosure?

This enclosure is made from ABS and has an IP67 ingress rating and IK08 impact rating. It is specified for operating temperatures from -40 C to 70 C and has a product weight of 0.214 kg.

Why choose the transparent cover version of this Boxco enclosure?

The transparent cover helps when internal indicators, displays, or visual inspections need to be checked without opening the enclosure. On this model, that visibility is combined with the screw-type cover design and the same IP67 and IK08 protective ratings listed for the enclosure.

What internal mounting features does the BC-ATS-081108 include?

This model includes mounting plate attachment points with brass inserted injection molding for securely fixing an internal mounting plate. It also includes pre-molded mounting screw nuts so DIN rail or other internal equipment can be fixed inside the enclosure body.

How does this enclosure help protect sensitive electronics?

The description specifies anti-static material to help protect sensitive electronic instruments from static electricity. It also notes high impact resistant construction and a precision-injected gasket designed to support strong waterproof and dust-proof performance.
