Boxco

Boxco S-Series 80x130x85mm Plastic Enclosure, IP67, IK08, ABS, Transparent Cover, Screw Type

SKU BC-ATS-081308
Log in to see price Trade pricing & online ordering for account holders
Log in or apply for a trade account →
Available to order
|

Overview

BC-ATS-081308 is a 80×130×85 mm ABS enclosure with a transparent cover from the Boxco S Series.

Features

  • S series enclosure's screw thread of the base for connecting cover is molded so that it has sufficient strength and not broken
  • Our electrical junction box is designed as 4 side sliding type to be strong against impact.
  • BOXCO's terminal box is suitable for mounting electrical components and it is available in ABS and polycarbonate.

Specifications

BC-ATS-081308Specifications from the official datasheetDownload datasheet PDF

Dimensions

Size W × L × H (cover included)
80×130×85 mm (3.15×5.12×3.35 in)
Mounting plate dimension M1 × M2
65 × 115 mm

Material

Material
ABS
Cover
Transparent
Mounting plates
0813 P (Plastic, P type), 0813 S (Steel, S type)

Protection & environment

IP rating
IP66/67
IK rating
IK08
Operating temperature
-40 ~ +70℃
Flammability rating (UL 94)
94-HB
Test conditions and notes1
  1. Dimensions and specifications are subject to change without notice.

Technical drawings

BC-ATS-081308 Dimensions (mm)
Dimensions (mm)

Downloads

FAQ

What are the key specifications of the Boxco S-Series BC-ATS-081308 enclosure?

This model measures 3.15 x 5.12 x 3.35 inches (80 x 130 x 85 mm) and is made from ABS with a transparent cover. It is rated IP67 for dust and water resistance and IK08 for impact resistance. The enclosure weight is 0.234 kg.

Is this enclosure suitable for outdoor environments?

Yes. The Boxco S-Series uses an ultraviolet stabilizer to help protect the enclosure in outdoor use. The product description notes that only minor color change may occur even after long-term exposure.

Can this enclosure help protect sensitive electronics from static electricity?

Yes. This model uses anti-static material intended to help protect sensitive electronic instruments from static electricity. That makes it a practical option for applications where static control is a consideration.

What temperature range can this plastic enclosure handle?

The rated operating temperature range is -40 degrees C to 70 degrees C. This makes it suitable for a wide range of industrial and commercial environments within that temperature window.

What internal mounting features does this enclosure include?

The enclosure includes internal mounting plate attachment points with brass inserted injection molding for secure plate fastening. It also has pre-molded mounting screw nuts that support mounting DIN rail or other internal equipment. These features are intended to help support heavier installed components inside the enclosure.

How does this model compare with a standard plastic enclosure for harsh environments?

This Boxco S-Series model stands out with its IP67 sealing, IK08 impact rating, UV-stabilized material for outdoor use, and anti-static construction. It also includes a transparent cover and built-in mounting features that are useful in equipment enclosure applications. Those details make it more specialized than a basic general-purpose plastic box.
