Boxco

Boxco S-Series 125×175×75mm Plastic Enclosure, IP67, IK08, PC, Grey Cover, Screw Type

SKU BC-CGS-121707-K
Log in to see price Trade pricing & online ordering for account holders
Log in or apply for a trade account →
Available to order
|

Overview

BC-CGS-121707-K is a 125×175×75 mm Polycarbonate (PC) enclosure with a grey cover from the Boxco K Series.

Features

  • BOXCO waterproof IP66/IP67 plastic enclosures have knockouts on both sides so it is easy to punch holes. 2. Our knock-outs enclosures are easy to make onsite installation of cable or wiring. 3. This series are made for electrical control box, junction box and many other applications.

Specifications

BC-CGS-121707-KSpecifications from the official datasheetDownload datasheet PDF

Dimensions

Size W × L × H (cover included)
125×175×75 mm (4.92×6.89×2.95 in)
Mounting plate dimension M1 × M2
110 × 159 mm

Material

Material
Polycarbonate (PC)
Cover
Grey
Mounting plates
1217 G (Plastic, G type), 1217 P (Plastic, P type), 1217 S (Steel, S type)

Protection & environment

IP rating
IP66/67
IK rating
IK08
Operating temperature
-40 ~ +110℃
Flammability rating (UL 94)
94-V-0, 5VA, HB
Test conditions and notes1
  1. Dimensions and specifications are subject to change without notice.

Technical drawings

BC-CGS-121707-K Dimensions (mm)
Dimensions (mm)

Downloads

FAQ

What are the main specifications of the Boxco S-Series BC-CGS-121707-K enclosure?

This model is a plastic screw-type enclosure with overall dimensions of 4.92 x 6.89 x 2.95 inches (125 x 175 x 75 mm). It is rated IP67 and IK08, uses PC material, has a grey cover, and weighs 0.5000 kg.

Is this enclosure suitable for demanding indoor or outdoor environments?

This model is designed for demanding environments because it carries an IP67 ingress protection rating and an IK08 impact rating. Its operating temperature range of -40 °C to 110 °C also supports use across a wide range of conditions.

What does the screw-type design mean for this enclosure?

This enclosure uses a screw-type cover, which is a common choice when a secure closed housing is needed. For buyers comparing enclosure styles, this model is specifically identified as a screw-type version within the Boxco S-Series.

Does this Boxco enclosure include any special base feature?

Yes. The product description states that this S-Series model has a knock out base. That can matter for buyers who need an enclosure variant with that base style rather than a plain base.

What kinds of applications is this enclosure typically used for?

This model is generally suited for protecting components that need a durable plastic enclosure with sealed environmental protection. Buyers often look at this type of enclosure for industrial or commercial applications where enclosure size, IP67 protection, and impact resistance are important selection factors.

What material and cover color does this model use?

This enclosure is made from PC material and comes with a grey cover. Those details help confirm the exact variant when matching a replacement or standardizing enclosure specifications across a project.
