Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Boxco

Boxco S-Series 80×110×70mm Plastic Enclosure, IP67, IK08, PC, Transparent Cover, Screw Type

SKU BC-CTS-081107-K
Log in to see price Trade pricing & online ordering for account holders
Log in or apply for a trade account →
Available to order
|

Overview

BC-CTS-081107-K is a 80×110×70 mm Polycarbonate (PC) enclosure with a transparent cover from the Boxco K Series.

Features

  • BOXCO waterproof IP66/IP67 plastic enclosures have knockouts on both sides so it is easy to punch holes. 2. Our knock-outs enclosures are easy to make onsite installation of cable or wiring. 3. This series are made for electrical control box, junction box and many other applications.

Specifications

BC-CTS-081107-KSpecifications from the official datasheetDownload datasheet PDF

Dimensions

Size W × L × H (cover included)
80×110×70 mm (3.15×4.33×2.76 in)

Material

Material
Polycarbonate (PC)
Cover
Transparent

Protection & environment

IP rating
IP66/67
IK rating
IK08
Operating temperature
-40 ~ +110℃
Flammability rating (UL 94)
94-V-0, 5VA, HB
Test conditions and notes1
  1. Dimensions and specifications are subject to change without notice.

Technical drawings

BC-CTS-081107-K Dimensions (mm)
Dimensions (mm)

Downloads

FAQ

What are the main specifications of the Boxco S-Series BC-CTS-081107-K enclosure?

This model measures 3.15 x 4.33 x 2.76 inches (80 x 110 x 70 mm). It is a plastic enclosure with a transparent cover, screw-type construction, IP67 protection, IK08 impact rating, and a stated operating temperature range of -40°C to 110°C.

What kind of environments is this enclosure designed for?

This enclosure is suited for demanding indoor or outdoor environments where protection from dust and water ingress is important. Its IP67 rating and IK08 impact rating make it appropriate for applications that need a durable protective housing.

Does this enclosure have a clear cover for viewing enclosed components?

Yes, this model includes a transparent cover. That makes it useful when visual access is needed without opening the enclosure.

What applications is this Boxco enclosure commonly used for?

This type of enclosure is typically used to protect components that need a compact, sealed plastic housing. Its size, transparent cover, and environmental ratings make it a practical choice for commercial and industrial equipment protection where visibility and enclosure strength both matter.

What does the screw-type design mean for this enclosure?

The product is identified as a screw-type enclosure, which distinguishes it within the Boxco S-Series. Buyers comparing enclosure styles may choose this version when they specifically need the screw-type format listed for their application or replacement requirement.

Does this model include any special base feature?

Yes, the product description states that this series has a knock out base. That can be a useful distinguishing feature when comparing it against enclosure series without that base design.
