Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Boxco

Boxco S-Series 80×110×85mm Plastic Enclosure, IP67, IK08, PC, Grey Cover, Screw Type

SKU BC-CGS-081108-K
Log in to see price Trade pricing & online ordering for account holders
Log in or apply for a trade account →
Available to order
|

Overview

BC-CGS-081108-K is a 80×110×85 mm Polycarbonate (PC) enclosure with a grey cover from the Boxco K Series.

Features

  • BOXCO waterproof IP66/IP67 plastic enclosures have knockouts on both sides so it is easy to punch holes. 2. Our knock-outs enclosures are easy to make onsite installation of cable or wiring. 3. This series are made for electrical control box, junction box and many other applications.

Specifications

BC-CGS-081108-KSpecifications from the official datasheetDownload datasheet PDF

Dimensions

Size W × L × H (cover included)
80×110×85 mm (3.15×4.33×3.35 in)

Material

Material
Polycarbonate (PC)
Cover
Grey

Protection & environment

IP rating
IP66/67
IK rating
IK08
Operating temperature
-40 ~ +110℃
Flammability rating (UL 94)
94-V-0, 5VA, HB
Test conditions and notes1
  1. Dimensions and specifications are subject to change without notice.

Technical drawings

BC-CGS-081108-K Dimensions (mm)
Dimensions (mm)

Downloads

FAQ

What are the main specifications of the Boxco S-Series BC-CGS-081108-K enclosure?

This model is a screw-type plastic enclosure with overall dimensions of 3.15 x 4.33 x 3.35 inches (80 x 110 x 85 mm). It is rated IP67 and IK08, uses PC construction, and has a grey cover. The listed product weight is 0.5000 kg.

Is this enclosure suitable for outdoor or washdown environments?

This enclosure carries an IP67 rating, which indicates strong protection against dust ingress and temporary immersion in water. That makes it a suitable option for demanding environments where sealing performance matters. Buyers should still confirm overall fit for their specific site conditions and compliance requirements.

What temperature range can this enclosure handle?

The listed operating temperature range for this model is -40 °C to 110 °C. That wide range makes it suitable for applications exposed to both low and high ambient temperatures. It is useful for buyers who need enclosure performance across varied industrial conditions.

What kind of applications is this Boxco enclosure commonly used for?

This enclosure is typically considered for applications that need a compact, sealed housing for protecting internal components from dust, water exposure, and physical impact. Its IP67 and IK08 ratings make it relevant for industrial and commercial environments where durability is important. The 80 x 110 x 85 mm size also suits installations needing a relatively compact enclosure footprint.

How does the screw-type design affect this enclosure compared with other enclosure styles?

This model uses a screw-type cover, which is a common choice when buyers want a more secure mechanical closure. Compared with non-screw closure styles, it is positioned as a more firmly fastened enclosure format. For this specific model, the screw-type design is one of its stated product features.

Does this enclosure include any base feature for flexibility in use?

Yes. The product description states that this S-Series model has a knock out base. That can be a relevant feature for buyers comparing enclosure options within the same family.

What warranty period is listed for this enclosure?

The listed warranty period for this model is 1 year. For procurement and support planning, that gives buyers a defined coverage term tied to this specific enclosure. Warranty scope and conditions should be confirmed at time of purchase.
