Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Boxco

Boxco S-Series 80x110x85mm Plastic Enclosure, IP67, IK08, PC, Grey Cover, Screw Type

SKU BC-CGS-081108
Log in to see price Trade pricing & online ordering for account holders
Log in or apply for a trade account →
In stock
|

Overview

BC-CGS-081108 is a 80×110×85 mm Polycarbonate (PC) enclosure with a grey cover from the Boxco S Series.

Features

  • S series enclosure's screw thread of the base for connecting cover is molded so that it has sufficient strength and not broken
  • Our electrical junction box is designed as 4 side sliding type to be strong against impact.
  • BOXCO's terminal box is suitable for mounting electrical components and it is available in ABS and polycarbonate.

Specifications

BC-CGS-081108Specifications from the official datasheetDownload datasheet PDF

Dimensions

Size W × L × H (cover included)
80×110×85 mm (3.15×4.33×3.35 in)
Mounting plate dimension M1 × M2
65 × 95 mm

Material

Material
Polycarbonate (PC)
Cover
Grey
Mounting plates
0811 P (Plastic, P type), 0811 S (Steel, S type)

Protection & environment

IP rating
IP66/67
IK rating
IK08
Operating temperature
-40 ~ +110℃
Flammability rating (UL 94)
94-V-0, 5VA, HB
Test conditions and notes1
  1. Dimensions and specifications are subject to change without notice.

Technical drawings

BC-CGS-081108 Dimensions (mm)
Dimensions (mm)

Downloads

FAQ

What applications is this Boxco S-Series plastic enclosure suited for?

This enclosure is suited for protecting electronic components and instruments in industrial, commercial, and outdoor equipment housings. Its anti-static material, impact-resistant construction, and sealed design make it a practical choice for applications that need durable environmental protection in a compact form factor.

What are the key specifications of this enclosure?

This model measures 3.15 x 4.33 x 3.35 inches (80 x 110 x 85 mm) and weighs 0.245 kg. It is a polycarbonate enclosure with a grey cover, screw-type closure, IP67 ingress protection, and IK08 impact resistance.

Is this enclosure suitable for outdoor or harsh environments?

Yes, this Boxco S-Series enclosure is designed for demanding environments, including outdoor use. It includes ultraviolet stabilizer for improved long-term outdoor durability and is rated IP67 for dust-tight and water-resistant protection, with an operating temperature range of -40°C to 110°C.

How does this model help protect sensitive electronics?

The enclosure uses anti-static material to help protect sensitive electronic instruments from static electricity. It is also made from high impact resistant material, which helps reduce the risk of breakage from external impact and during enclosure machining processes such as hole or press processing.

What makes this screw-type enclosure different from a basic plastic box?

This model combines a screw-type cover with molded strength and mounting features intended for more demanding equipment protection. It includes internal mounting plate attachment points, pre-molded mounting screw nuts, and a precision-injected gasket system to provide a more robust enclosure option than a basic general-purpose box.

What internal mounting features does this enclosure include?

This enclosure includes internal mounting plate attachment points formed with brass inserted injection molding to support heavier installed equipment. It also has pre-molded mounting screw nuts that can be used for securing compatible internal hardware such as DIN rail accessories.
