Boxco

Boxco S-Series 80x130x70mm Plastic Enclosure, IP67, IK08, PC, Transparent Cover, Screw Type

SKU BC-CTS-081307
Log in to see price Trade pricing & online ordering for account holders
Log in or apply for a trade account →
Available to order
|

Overview

BC-CTS-081307 is a 80×130×70 mm Polycarbonate (PC) enclosure with a transparent cover from the Boxco S Series.

Features

  • S series enclosure's screw thread of the base for connecting cover is molded so that it has sufficient strength and not broken
  • Our electrical junction box is designed as 4 side sliding type to be strong against impact.
  • BOXCO's terminal box is suitable for mounting electrical components and it is available in ABS and polycarbonate.

Specifications

BC-CTS-081307Specifications from the official datasheetDownload datasheet PDF

Dimensions

Size W × L × H (cover included)
80×130×70 mm (3.15×5.12×2.76 in)
Mounting plate dimension M1 × M2
65 × 115 mm

Material

Material
Polycarbonate (PC)
Cover
Transparent
Mounting plates
0813 P (Plastic, P type), 0813 S (Steel, S type)

Protection & environment

IP rating
IP66/67
IK rating
IK08
Operating temperature
-40 ~ +110℃
Flammability rating (UL 94)
94-V-0, 5VA, HB
Test conditions and notes1
  1. Dimensions and specifications are subject to change without notice.

Technical drawings

BC-CTS-081307 Dimensions (mm)
Dimensions (mm)

Downloads

FAQ

What applications is the Boxco S-Series 80x130x70mm plastic enclosure suited for?

This enclosure is suited for protecting electronic equipment in industrial and outdoor environments where dust, water resistance, and impact protection matter. Its transparent cover also makes it useful when visual inspection of enclosed components is needed without opening the box.

How durable is this enclosure for outdoor or exposed environments?

This model is rated IP67 for dust-tight and water-resistant protection and IK08 for impact resistance. It also uses ultraviolet stabilizer material to help reduce visible color change during long-term outdoor use.

What material is this Boxco enclosure made from?

This model is made from polycarbonate (PC) and includes a transparent cover. The product description also notes anti-static material properties and high impact resistance to help protect sensitive electronic instruments.

What are the dimensions of this enclosure?

The enclosure measures 3.15 x 5.12 x 2.76 inches, which corresponds to 80 x 130 x 70 mm. This size is useful when you need a compact enclosure with room for internal mounting hardware and equipment.

What temperature range can this enclosure handle?

This model is specified for temperatures from -40 degrees C to 110 degrees C. That range makes it appropriate for demanding environments where standard plastic enclosures may not be sufficient.

What internal mounting features does this enclosure include?

The enclosure includes internal mounting plate attachment points with brass inserted injection molding to support heavier installed equipment. It also has pre-molded mounting screw nuts that can be used to secure DIN rail or other internal equipment.

What makes this screw-type enclosure different from a basic plastic box?

This Boxco S-Series model combines a screw-type cover, IP67 sealing, IK08 impact resistance, and a transparent polycarbonate cover in one enclosure. It also adds UV-stabilized, anti-static, high-impact material and molded attachment points that go beyond a basic general-purpose box.
