Boxco

Boxco S-Series 150x200x130mm Plastic Enclosure, IP67, IK08, ABS, Transparent Cover, Screw Type

SKU BC-ATS-152013
Log in to see price Trade pricing & online ordering for account holders
Log in or apply for a trade account →
In stock
|

Overview

BC-ATS-152013 is a 150×200×130 mm ABS enclosure with a transparent cover from the Boxco S Series.

Features

  • S series enclosure's screw thread of the base for connecting cover is molded so that it has sufficient strength and not broken
  • Our electrical junction box is designed as 4 side sliding type to be strong against impact.
  • BOXCO's terminal box is suitable for mounting electrical components and it is available in ABS and polycarbonate.

Specifications

BC-ATS-152013Specifications from the official datasheetDownload datasheet PDF

Dimensions

Size W × L × H (cover included)
150×200×130 mm (5.91×7.87×5.12 in)
Mounting plate dimension M1 × M2
129 × 179 mm

Material

Material
ABS
Cover
Transparent
Mounting plates
1520 G (Plastic, G type), 1520 P (Plastic, P type), 1520 S (Steel, S type)

Protection & environment

IP rating
IP66/67
IK rating
IK08
Operating temperature
-40 ~ +70℃
Flammability rating (UL 94)
94-HB
Test conditions and notes1
  1. Dimensions and specifications are subject to change without notice.

Technical drawings

BC-ATS-152013 Dimensions (mm)
Dimensions (mm)

Downloads

FAQ

What applications is the Boxco S-Series 150x200x130mm enclosure suited for?

This enclosure is suited for protecting industrial and commercial electronics that need a sealed non-metallic housing. Its anti-static ABS construction and transparent screw-type cover make it a practical option for control components, monitoring devices, and other sensitive equipment housed in indoor or outdoor environments.

Is this enclosure appropriate for outdoor use?

Yes. Boxco states that this S-Series enclosure includes an ultraviolet stabilizer to support outdoor usage and reduce visible color change over time. The IP67 rating also indicates strong protection against dust and water ingress in demanding environments.

What level of environmental and impact protection does this model provide?

This model is rated IP67 and IK08. That means it is designed for strong dust and water resistance and offers solid impact resistance for environments where the enclosure may be exposed to physical contact or general industrial wear.

What material is this enclosure made from, and why does it matter?

This model is made from ABS plastic and uses anti-static material properties to help protect sensitive electronic instruments from static electricity. Boxco also describes the housing as high impact resistant, which helps reduce breakage during processing and in service.

What are the dimensions and weight of this enclosure?

The enclosure measures 5.91 x 7.87 x 5.12 inches, which corresponds to 150 x 200 x 130 mm. Its listed weight is 0.546 kg, making it a moderate-size enclosure for applications that need more internal space than compact junction boxes.

Does this enclosure support internal mounting hardware and equipment retention?

Yes. The product description states that it includes mounting plate attachment points and pre-molded mounting screw nuts. These features are intended to support secure placement of internal plates, DIN rail, or other equipment inside the enclosure.

What temperature range is this enclosure rated for?

This model is rated for use from -40 °C to 70 °C. That range makes it suitable for many industrial and outdoor environments where the enclosure may be exposed to low or elevated ambient temperatures.
