Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Boxco S-Series 100x185x70mm Plastic Enclosure, IP67, IK08, ABS, Transparent Cover, Screw Type

SKU:

BC-ATS-101807

Notify me when it's back in stock

Description

For Boxco S-Series, Ultraviolet Stabilizer is added to protect the enclosures for outdoor usage. Few colour changes will be noticed even after a long time of use. Anti-static material is used to protect sensitive electronic instruments from static electricity. It is made of high impact resistant material which is very strong against external impact and also prevents breakage during hole and press processing. Special spec can be added besides standard specification. We can supply optimized products with the spec and material you choose.

Features

Mounting Plate Attachment Point – Internal mounting plate can be fixed tightly onto the brass inserted injection molding to handle heavy equipment installed inside the enclosure
Pre-molded Mounting Screw Nuts – You can easily fix DIN RAIL or other equipment on to the pre molded Screw nuts
Gasket – The gasket in injected by super precise CNC robot machine to product excellent waterproof and dust-proof performance
Cover Bolt Attachment Point – Screw thread was made in injection molding to ensure maximum strength

Specifications

Brand

Boxco
Series

Boxco S Series
Standards Met

CE,TUV,UL
Operating Temperature

-40°C~70°C
Warranty

1 Year
Length

10 cm
Width

18.5 cm
Height

7 cm
Weight

0.31 kg

File Downloads

::specification::

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

Is the Boxco S-Series BC-ATS-101807 suitable for outdoor use?

Yes. This enclosure uses an ultraviolet stabilizer to help protect the housing during outdoor use and reduce visible color change over time. Its IP67 rating also indicates strong protection against dust and water ingress when properly closed.

What are the main material and protection specifications for this enclosure?

This model is made from ABS plastic and has a transparent cover with a screw-type closure. It is rated IP67 for dust and water protection and IK08 for impact resistance. Boxco also states the material is high impact resistant and designed to resist breakage during hole and press processing.

Can this enclosure be used for sensitive electronic equipment?

It can be a good fit for sensitive electronics because Boxco specifies anti-static material for protection against static electricity. That makes this model more suitable for electronics housings than a generic plastic box without that feature. Final suitability still depends on the needs of the specific equipment inside.

What size is the BC-ATS-101807 enclosure?

This enclosure measures 3.94 x 7.28 x 2.76 inches, which is 100 x 185 x 70 mm. Those dimensions make it a compact rectangular enclosure for applications that need more internal length than a small junction-style box. Buyers should confirm internal clearance based on their own components and mounting layout.

Does this model support mounting internal components or rails?

Yes. Boxco lists internal mounting plate attachment points with brass inserted injection molding so a mounting plate can be fixed tightly inside the enclosure. It also includes pre-molded mounting screw nuts that can be used to secure DIN rail or other internal equipment.

What operating temperatures can this enclosure handle?

The specified operating temperature range for this model is -40 degrees C to 70 degrees C. That range supports use in both cold and moderately hot environments. It is important to make sure the electronics installed inside are also rated for the same conditions.
