Boxco

Boxco S-Series 80×110×85mm Plastic Enclosure, IP67, IK08, PC, Transparent Cover, Screw Type

SKU:
BC-CTS-081108-K
Please for Pricing
|

Description

Features

  • Screw type
  • This series has a knock out base

Specifications
  • Brand
    Boxco
  • Series
    Boxco S Series
  • Standards Met
    CE,TUV,UL
  • Operating Temperature
    -40°C~110°C
  • Warranty
    1 Year
  • Length
    8 cm
  • Width
    11 cm
  • Height
    8.5 cm
  • Weight
    0.5 kg

File Downloads

::specification::

Payment & Security

Payment methods

  • American Express
  • Apple Pay
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Union Pay
  • Visa

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

What are the key specifications of the Boxco S-Series BC-CTS-081108-K enclosure?

This model measures 3.15 x 4.33 x 3.35 inches (80 x 110 x 85 mm) and is made from polycarbonate (PC). It has a transparent cover, a screw-type closure, an IP67 ingress rating, and an IK08 impact rating. The listed product weight is 0.5000 kg, and the warranty period is 1 year.

What does the transparent cover offer on this enclosure?

The transparent cover allows internal components to remain visible without opening the enclosure. That can be useful when the application benefits from quick visual inspection while keeping the box closed. This model combines that clear cover with a screw-type design for a more secure closure.

Is this enclosure suitable for dusty or wet environments?

This model is rated IP67, which indicates strong protection against dust ingress and temporary immersion conditions. For buyers comparing enclosure options, that makes it a stronger choice than general-purpose indoor boxes with lower sealing performance. It is intended for applications where environmental protection is an important requirement.

What temperature range can this Boxco enclosure handle?

The specified operating temperature range is -40 °C to 110 °C. That makes this model suitable for applications that face both low-temperature and elevated-temperature conditions within that range. Buyers should match the rest of their assembly to the same thermal limits.

How does this model differ from a solid-cover enclosure?

This version uses a transparent cover instead of an opaque one, so the contents can be seen without opening the box. It is also identified as a screw-type enclosure and includes a knock out base as part of the S-Series feature set. If visibility of internal indicators or labels matters, this version may be the better fit.

What kinds of applications is this enclosure typically considered for?

This enclosure is generally suited to protecting small internal assemblies that need a sealed plastic housing with visibility through the lid. Its IP67 and IK08 ratings make it relevant for applications where both environmental sealing and impact resistance matter. Buyers should confirm that the enclosure dimensions and internal space fit their specific components.

Does this enclosure include any feature that helps with enclosure preparation or adaptation?

Yes. The product description states that this S-Series model has a knock out base. For buyers evaluating compatibility with their enclosure layout needs, that is a notable model-specific feature alongside the screw-type cover design.
