Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Boxco

Boxco P-Series 100x150x85mm Plastic Enclosure, IP67, IK08, ABS, Transparent Cover, Molded Hinge and Latch Type

SKU BC-ATP-101508
Log in to see price Trade pricing & online ordering for account holders
Log in or apply for a trade account →
Available to order
|

Overview

BC-ATP-101508 is a 100×150×85 mm ABS enclosure with a transparent cover from the Boxco P Series.

Features

  • BOXCO control box with polyurathane gasket is designed to prevent the penetration of rain and dust perfectly as roof is protruded from top and bottom of the base.
  • Our thermoplastic enclosures are easy to separate cover and base so that user can assemble enclosure for machining or printing.
  • Hinge is integrated with enclosure and main parts of draw latch are made of stainless steel to be solid.
  • Hinge connecting pins and draw latch are made of stainless steel and plastic to prevent rust.

Specifications

BC-ATP-101508Specifications from the official datasheetDownload datasheet PDF

Dimensions

Size W × L × H (cover included)
100×150×85 mm (3.94×5.91×3.35 in)
Mounting plate dimension M1 × M2
65 × 115 mm

Material

Material
ABS
Cover
Transparent
Mounting plates
0813 P (Plastic, P type), 0813 S (Steel, S type)

Protection & environment

IP rating
IP66/67
IK rating
IK08
Operating temperature
-40 ~ +70℃
Flammability rating (UL 94)
94-HB
Test conditions and notes1
  1. Dimensions and specifications are subject to change without notice.

Technical drawings

BC-ATP-101508 Dimensions (mm)
Dimensions (mm)

Downloads

FAQ

What environments is the Boxco P-Series BC-ATP-101508 designed for?

This enclosure is built for demanding indoor and outdoor use where protection from dust, water, and impact matters. It is rated IP67 for ingress protection and IK08 for impact resistance, and the ABS material includes an ultraviolet stabilizer to help reduce visible color change over time outdoors.

What are the dimensions of this plastic enclosure?

This model measures 3.94 x 5.91 x 3.35 inches, which corresponds to 100 x 150 x 85 mm. Those dimensions make it a compact enclosure option for protecting electronic components while still offering useful internal space.

What makes this enclosure different from a basic plastic project box?

This model includes features aimed at industrial and commercial use, including a transparent cover, molded hinge and latch design, IP67 sealing, and IK08 impact resistance. It also has pre-molded mounting screw nuts, roof protection features, and brass-inserted mounting plate attachment points for more demanding applications.

Is this enclosure suitable for protecting sensitive electronic equipment?

Yes, the product description states that anti-static material is used to help protect sensitive electronic instruments from static electricity. It is also made from high impact resistant ABS to better withstand external impact and reduce breakage during processing.

What temperature range can the BC-ATP-101508 handle?

This enclosure is specified for use from -40 °C to 70 °C. That range supports use in both cold and hot operating environments, provided the application stays within those published limits.

Does this model include a transparent cover, and why would that matter?

Yes, this version comes with a transparent cover. That can be useful when you need to visually inspect indicators, labels, or internal components without opening the enclosure.
