Boxco

Boxco P-Series 160x210x130mm Plastic Enclosure, IP67, IK08, ABS, Grey Cover, Molded Hinge and Latch Type

SKU:
BC-AGP-162113
Please for Pricing
|

Description

For Boxco P-Series,Ultraviolet Stabilizer is added to protect the enclosures for outdoor usage. Few colour changes will be noticed even after a long time of use. Anti-static material is used to protect sensitive electronic instruments from static electricity. It is made of high impact resistant material which is very strong against external impact and also prevents breakage during hole and press processing. Special spec can be added besides standard specification. We can supply optimized products with the spec and material you choose.

Features

  • Latch - Main part of the draw latch is made of stainless steel so it is very strong.
  • Pre-molded Mounting Screw Nuts – You can easily fix DIN RAIL or other equipment on to the pre molded Screw nuts
  • Roof Protection – Both ends of the P series are protruded to protect against penetration of water when using it outdoor and penetration of dust when opening/closing the cover
  • Gasket – The gasket in injected by super precise CNC robot machine to product excellent waterproof and dust-proof performance
  • Mounting Plate Attachment Point – Internal mounting plate can be fixed tightly onto the brass inserted injection molding to handle heavy equipment installed inside the enclosure
  • Integrated Hinge – Hinge is made of plastic and is integrated with the enclosure. Bearing is made of stainless steel to increase the life span.

Specifications
  • Brand
    Boxco
  • Series
    Boxco P Series
  • Standards Met
    CE,TUV,UL
  • Operating Temperature
    -40°C~70°C
  • Warranty
    1 Year
  • Length
    16 cm
  • Width
    21 cm
  • Height
    13 cm
  • Weight
    0.53 kg

File Downloads

::specification::

Payment & Security

Payment methods

  • American Express
  • Apple Pay
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Union Pay
  • Visa

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

What is this Boxco P-Series enclosure typically used for?

This enclosure is used to protect electrical or electronic equipment in industrial and commercial environments where dust, moisture, and impact resistance matter. Its molded hinge and latch design makes it a practical choice for control, monitoring, or protection applications that need a durable non-metallic housing.

What are the exact dimensions of this enclosure?

This model measures 6.30 x 8.27 x 5.12 inches, which is 160 x 210 x 130 mm. Those dimensions make it a mid-size enclosure suited for components that need more internal space than compact junction-style boxes.

Is this enclosure suitable for outdoor or washdown environments?

This model is rated IP67, which indicates strong protection against dust ingress and temporary immersion in water under rated conditions. The product description also notes UV stabilizer protection and roof-style edge protection to help support outdoor use.

How durable is the enclosure against physical impact?

This enclosure carries an IK08 impact rating, which indicates good resistance to mechanical impact for industrial enclosure use. It is also made from high-impact resistant ABS, and the description highlights strength during machining processes such as hole or press work.

What material is this enclosure made from, and why does that matter?

This model is made from ABS plastic with a grey cover. ABS is commonly selected when buyers want a lightweight, corrosion-resistant enclosure with solid impact performance instead of a metal housing.

What temperature range can this enclosure handle?

The listed operating temperature range for this model is -40 °C to 70 °C. That range supports use in both cold and warm industrial environments, provided the full application stays within those limits.

Does this enclosure support internal mounting hardware or plates?

Yes, the product description states that it includes pre-molded mounting screw nuts and mounting plate attachment points. These features help support internal equipment mounting and make the enclosure more adaptable for component-heavy applications.
