Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Boxco

Boxco P-Series 300x400x180mm Plastic Enclosure, IP67, IK08, ABS, Grey Cover, Molded Hinge and Latch Type

SKU BC-AGP-304018
Log in to see price Trade pricing & online ordering for account holders
Log in or apply for a trade account →
In stock
|

Overview

BC-AGP-304018 is a 300×400×180 mm ABS enclosure with a grey cover from the Boxco P Series.

Features

  • BOXCO control box with polyurathane gasket is designed to prevent the penetration of rain and dust perfectly as roof is protruded from top and bottom of the base.
  • Our thermoplastic enclosures are easy to separate cover and base so that user can assemble enclosure for machining or printing.
  • Hinge is integrated with enclosure and main parts of draw latch are made of stainless steel to be solid.
  • Hinge connecting pins and draw latch are made of stainless steel and plastic to prevent rust.

Specifications

BC-AGP-304018Specifications from the official datasheetDownload datasheet PDF

Dimensions

Size W × L × H (cover included)
300×400×180 mm (11.81×15.75×7.09 in)
Mounting plate dimension M1 × M2
264 × 364 mm

Material

Material
ABS
Cover
Grey
Mounting plates
3040 P (Plastic, P type), 3040 S (Steel, S type)

Protection & environment

IP rating
IP66/67
IK rating
IK08
Operating temperature
-40 ~ +70℃
Flammability rating (UL 94)
94-HB
Test conditions and notes1
  1. Dimensions and specifications are subject to change without notice.

Technical drawings

BC-AGP-304018 Dimensions (mm)
Dimensions (mm)

Downloads

FAQ

What applications is this Boxco P-Series enclosure best suited for?

This model is suited for protecting industrial and commercial electronics that need a durable non-metallic enclosure in indoor or outdoor environments. Its IP67 sealing, IK08 impact rating, UV-stabilized ABS construction, and molded hinge and latch design make it a practical choice for control, monitoring, or instrumentation housings where dust, water, and physical exposure are concerns.

Is this enclosure suitable for outdoor use?

Yes. The product description states that Boxco adds an ultraviolet stabilizer to the P-Series to improve outdoor durability and reduce long-term color change. It also includes roof protection features and a precision-injected gasket to help maintain waterproof and dust-proof performance.

What protection ratings does model BC-AGP-304018 have?

This enclosure is rated IP67 for protection against dust and water ingress and IK08 for impact resistance. It is made from ABS and is described as high impact resistant material, which supports demanding industrial enclosure use.

What are the dimensions of this enclosure?

The listed size for this model is 11.81 x 15.75 x 7.09 inches, which corresponds to 300 x 400 x 180 mm. That larger format gives more internal space than compact junction-style enclosures and makes it better suited for applications requiring additional room inside the housing.

What makes this P-Series enclosure different from a basic plastic enclosure box?

This model includes several design details beyond a basic box, including a molded hinge, latch-type closure, roof protection geometry, pre-molded mounting screw nuts, and mounting plate attachment points. It is also specified with IP67 and IK08 ratings, UV stabilization for outdoor use, and anti-static material for protection of sensitive electronic instruments.

What temperature range can this enclosure handle?

The specified operating temperature range is -40 °C to 70 °C. That makes it suitable for a wide range of industrial and outdoor environments where both low-temperature and elevated-temperature exposure may occur.
