Boxco P-Series 400x500x200mm Plastic Enclosure, IP67, IK08, ABS, Grey Cover, Molded Hinge and Latch Type

SKU:

BC-AGP-405020

Notify me when it's back in stock

Description

For Boxco P-Series,Ultraviolet Stabilizer is added to protect the enclosures for outdoor usage. Few colour changes will be noticed even after a long time of use. Anti-static material is used to protect sensitive electronic instruments from static electricity. It is made of high impact resistant material which is very strong against external impact and also prevents breakage during hole and press processing. Special spec can be added besides standard specification. We can supply optimized products with the spec and material you choose.

Features

Latch - Main part of the draw latch is made of stainless steel so it is very strong.
Pre-molded Mounting Screw Nuts – You can easily fix DIN RAIL or other equipment on to the pre molded Screw nuts
Roof Protection – Both ends of the P series are protruded to protect against penetration of water when using it outdoor and penetration of dust when opening/closing the cover
Gasket – The gasket in injected by super precise CNC robot machine to product excellent waterproof and dust-proof performance
Mounting Plate Attachment Point – Internal mounting plate can be fixed tightly onto the brass inserted injection molding to handle heavy equipment installed inside the enclosure
Integrated Hinge – Hinge is made of plastic and is integrated with the enclosure. Bearing is made of stainless steel to increase the life span.

Specifications

Brand

Boxco
Series

Boxco P Series
Standards Met

CE,TUV,UL
Operating Temperature

-40°C~70°C
Warranty

1 Year
Length

40 cm
Width

50 cm
Height

20 cm
Weight

9.35 kg

File Downloads

::specification::

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

What applications is this Boxco P-Series plastic enclosure commonly used for?

This enclosure is suited for protecting control components, instrumentation, and other industrial equipment that need a sealed non-metallic housing. Its large 400 x 500 x 200 mm size and internal mounting plate attachment points make it a practical choice for larger assemblies in commercial and industrial environments.

Is this enclosure suitable for outdoor use?

Yes. The product description states that an ultraviolet stabilizer is added for outdoor usage, helping reduce visible color change over long-term exposure. It also includes roof protection features and an injected gasket designed to support strong water and dust resistance.

How much protection does this enclosure provide against dust, water, and impact?

This model is rated IP67 and IK08. That means it is built for strong protection against dust ingress and temporary immersion conditions, while also offering solid impact resistance for demanding industrial environments.

What material is this enclosure made from?

This model is made from ABS and uses anti-static material to help protect sensitive electronic instruments from static electricity. The description also notes that the enclosure uses high impact resistant material to improve durability during use and processing.

What are the exact size and weight of this enclosure?

This enclosure measures 15.75 x 19.69 x 7.87 inches, which corresponds to 400 x 500 x 200 mm. Its listed weight is 9.354 kg, making it a substantial enclosure intended for larger protected assemblies.

What temperature range can this enclosure handle?

The listed operating temperature range is -40 °C to 70 °C. This makes it appropriate for a wide range of indoor and outdoor industrial environments where temperature exposure is a concern.

What distinguishes this molded hinge and latch version from simpler enclosure styles?

This version includes an integrated plastic hinge with a stainless steel bearing, plus a latch whose main draw-latch component is stainless steel. Compared with more basic covers, these features support repeated access, durability, and secure closure in demanding applications.
