Boxco

Boxco P-Series 100x150x85mm Plastic Enclosure, IP67, IK08, PC, Transparent Cover, Molded Hinge and Latch Type

SKU BC-CTP-101508
Log in to see price Trade pricing & online ordering for account holders
Log in or apply for a trade account →
Available to order
|

Overview

BC-CTP-101508 is a 100×150×85 mm Polycarbonate (PC) enclosure with a transparent cover from the Boxco P Series.

Features

  • BOXCO control box with polyurathane gasket is designed to prevent the penetration of rain and dust perfectly as roof is protruded from top and bottom of the base.
  • Our thermoplastic enclosures are easy to separate cover and base so that user can assemble enclosure for machining or printing.
  • Hinge is integrated with enclosure and main parts of draw latch are made of stainless steel to be solid.
  • Hinge connecting pins and draw latch are made of stainless steel and plastic to prevent rust.

Specifications

BC-CTP-101508Specifications from the official datasheetDownload datasheet PDF

Dimensions

Size W × L × H (cover included)
100×150×85 mm (3.94×5.91×3.35 in)
Mounting plate dimension M1 × M2
65 × 115 mm

Material

Material
Polycarbonate (PC)
Cover
Transparent
Mounting plates
0813 P (Plastic, P type), 0813 S (Steel, S type)

Protection & environment

IP rating
IP66/67
IK rating
IK08
Operating temperature
-40 ~ +110℃
Flammability rating (UL 94)
94-V-0, 5VA, HB
Test conditions and notes1
  1. Dimensions and specifications are subject to change without notice.

Technical drawings

BC-CTP-101508 Dimensions (mm)
Dimensions (mm)

Downloads

FAQ

What applications is this Boxco P-Series enclosure best suited for?

This model is suited for protecting electronics and control components in industrial, commercial, and outdoor environments where a sealed plastic enclosure is needed. Its transparent cover also makes it practical when visual inspection of internal indicators or components is useful without opening the box.

Is this enclosure suitable for outdoor use?

Yes. The product description states that an ultraviolet stabilizer is added for outdoor usage, helping reduce color change over time. It also includes roof protection features and an injected gasket to support waterproof and dust-proof performance.

What does the IP67 rating mean for this enclosure?

IP67 indicates this enclosure is designed to provide strong protection against dust ingress and water exposure in demanding environments. For buyers comparing enclosure protection levels, this makes it a solid choice for applications that require a sealed housing for sensitive equipment.

What material is this enclosure made from, and why does it matter?

This model is made from polycarbonate (PC) with a transparent cover. The description also notes high impact resistance and anti-static material properties, which can help protect sensitive electronic instruments while offering better durability during processing and use.

What are the operating temperature limits for this enclosure?

This enclosure is rated for temperatures from -40 degrees C to 110 degrees C. That range makes it appropriate for applications exposed to both low and high ambient temperatures, provided the rest of the system is rated for the same conditions.

Does this enclosure support internal mounting hardware or plates?

Yes. The product description states that it includes pre-molded mounting screw nuts for fixing DIN rail or other equipment, and it also has internal mounting plate attachment points. Those features make it better suited for organized internal component mounting than a plain empty box.
