Boxco

Boxco P-Series 400x500x200mm Plastic Enclosure, IP67, IK08, PC, Transparent Cover, Molded Hinge and Latch Type

SKU:
BC-CTP-405020
Please for Pricing
|

Description

For Boxco P-Series,Ultraviolet Stabilizer is added to protect the enclosures for outdoor usage. Few colour changes will be noticed even after a long time of use. Anti-static material is used to protect sensitive electronic instruments from static electricity. It is made of high impact resistant material which is very strong against external impact and also prevents breakage during hole and press processing. Special spec can be added besides standard specification. We can supply optimized products with the spec and material you choose.

Features

  • Latch - Main part of the draw latch is made of stainless steel so it is very strong.
  • Pre-molded Mounting Screw Nuts – You can easily fix DIN RAIL or other equipment on to the pre molded Screw nuts
  • Roof Protection – Both ends of the P series are protruded to protect against penetration of water when using it outdoor and penetration of dust when opening/closing the cover
  • Gasket – The gasket in injected by super precise CNC robot machine to product excellent waterproof and dust-proof performance
  • Mounting Plate Attachment Point – Internal mounting plate can be fixed tightly onto the brass inserted injection molding to handle heavy equipment installed inside the enclosure
  • Integrated Hinge – Hinge is made of plastic and is integrated with the enclosure. Bearing is made of stainless steel to increase the life span.

Specifications
  • Brand
    Boxco
  • Series
    Boxco P Series
  • Standards Met
    CE,TUV,UL
  • Operating Temperature
    -40°C~110°C
  • Warranty
    1 Year
  • Length
    40 cm
  • Width
    50 cm
  • Height
    20 cm
  • Weight
    11.16 kg

File Downloads

::specification::

Payment & Security

Payment methods

  • American Express
  • Apple Pay
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Union Pay
  • Visa

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

What applications is the Boxco P-Series BC-CTP-405020 plastic enclosure suited for?

This enclosure is suited for protecting industrial and commercial equipment that needs a sealed non-metallic housing in indoor or outdoor environments. Its high-impact polycarbonate construction, transparent cover, and molded hinge and latch design make it a practical choice where visibility, durability, and environmental protection are important.

How large is the BC-CTP-405020 enclosure?

This model measures 15.75 x 19.69 x 7.87 inches, which corresponds to 400 x 500 x 200 mm. That size makes it a larger enclosure option for applications that need more internal room for mounted components and accessories.

What environmental protection ratings does this enclosure have?

The BC-CTP-405020 is rated IP67 for protection against dust and water ingress and IK08 for impact resistance. Boxco also states the P-Series includes ultraviolet stabilizer for outdoor use and a gasket designed for strong waterproof and dust-proof performance.

What material is this enclosure made from, and why does it matter?

This model is made from polycarbonate (PC), a high-impact resistant plastic used to help withstand external impact and reduce breakage during machining operations. Boxco also notes that anti-static material is used in the P-Series to help protect sensitive electronic instruments from static electricity.

What kind of cover and access design does this Boxco enclosure use?

This version has a transparent cover along with a molded hinge and latch-type closure. The integrated plastic hinge uses a stainless steel bearing to improve service life, and the main part of the draw latch is made of stainless steel for added strength.

Can this enclosure handle outdoor temperature exposure?

This enclosure is specified for temperatures from -40 °C to 110 °C. Combined with the UV-stabilized P-Series housing and roof protection design, it is intended for demanding environments where weather exposure is a concern.

Is the BC-CTP-405020 compatible with internal mounting hardware?

Yes. Boxco states the enclosure includes pre-molded mounting screw nuts for fixing DIN rail or other equipment, and it also has internal mounting plate attachment points with brass inserted injection molding to support heavier installed equipment.
